- Page 1 STAINLESS STEEL GAS GRILL USE AND CARE GUIDE MODEL NO.: 720-0036-HD-05 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE.
-
Page 2: Table Of Contents
TABLE OF CONTENT Pages Pages SECTION ONE SECTION THREE Importance Care and maintenance Precautions Care and maintenance of the side burner Placement of the grill Troubleshooting SECTION TWO SECTION FOUR Screw description Exploded View Assembly Instructions 5-11 Parts List How to use the retention kit Grilling hints Propane tank assembly Grill cooking chart... -
Page 3: Importance
IMPORTANCE * * * * * * FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid 4. If odor continues, immediately call your gas supplier or your fire department. FOR YOUR SAFETY 1. -
Page 4: Precautions
Use a covered hand when opening the grill lid. Never When properly cared for, your 720-0036- HD-05 lean over an open grill. (Charmglow) Grill will give safe, reliable service for many years. However, extreme care must be used WHEN LIGHTING A BURNER, ALWAYS PAY since the grill produces intense heat and that can CLOSE ATTENTION TO WHAT YOU ARE DOING. -
Page 5: Placement Of The Grill
GRILL. mounted correctly for safe operation. The 720-0036-HD-05 (Charmglow) Grill is designed for Clean the grill with caution. Avoid steam burns; do not optimum performance without the use of briquettes. Do use a wet sponge or cloth to clean the grill while it is hot. -
Page 6: Screw Description
Screw description ! ! $ " % & ' ( ) * " ! ! ! -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. Attention: Please lock the caster during the process of installation of the grill. TOOLS REQUIRED: Philips head screwdriver(not provide),monkey wrench(not provide) Step 1: Assemble two regular casters to the right side panels and caster with brakes on the left side panel as shown figure below.. Step 2: : Assemble bottom panel to side panels with eight (8) 1/4*38 mm screws as shown figure below... - Page 8 Step 3: Assemble the back panel to the two sides panel. with four (4) 1/4*12mm screws as shown figure below. Step 4: Assemble the cart frame to the front side of the side panel with four (4) 1/4*38mm screws . Attention: Please do not screw cart frame too tight in the first of beginning, in order to place next step.
- Page 9 : Remove the head unit of grill from carton. Insert the upper portion of the grill onto the cart from Step5 the top with four (4)1/4*12mm screws. Caution!! The firebox is heavy, and we recommend two or more people to lift up firebox. : 1.Place flame tamers (3) on to the fire box as show figure below.
- Page 10 :Use four (4)1/4*12mm screws to install the rear panel as show below. Step 7 : Assemble side burner with (8) 1/4*12mm screws as figure show below . Step8...
- Page 11 SIDE BURNER ASSEMBLY INSTRUCTIONS Side burner valve assembly: Step 1: Insert valve assembly through top of side Step 2: Remove 4(four) screws & washers panel from the “U” brackets on the side burner Valve (Side panel, right #23) Step 3: Insert valve stem assembly into burner Step 4: Insert valve stem assembly through knob venturi hole to the control panel...
- Page 12 First assemble the door handle to the door with the screw which packaged in the condiment rack Step 9: then assemble the two layer doors to the grill with two (2) double ended screws. :Assemble the condiment rack inside of the left door. Step 10...
- Page 13 Assemble the motor bracket to the fire box with two (2) 1/4*10mm screws. Step11...
-
Page 14: How To Use The Retention Kit
How to use the retention kit 1. Facing the back of the grill, the tank 2. Put a liquid propane tank into the hole retention kit is located on your left side. provided and wrap around with the rubber retention 3. -
Page 15: Propane Tank Assembly
PROPANE TANK ASSEMBLY Attach propane gas tank to regulator inlet fitting by turning the regulator clockwise as shown in figure below. < R X U J D V J U < R X U J D V J U < R X U J D V J U <... -
Page 16: Your Gas Grill Is Ready To Use
Your gas grill is ready to use... -
Page 17: Gas Hook Up
Total gas consumption (per hour) of The 720-0036-HD- Your 720-0036-HD-05 (Charmglow) grill is equipped 05 (Charmglow) Grill with all burners on “HI”: with gas supply orifices for use only with liquid propane gas. It is also equipped with a high capacity Main burners 36,000 Btu/hr. -
Page 18: Installer Final Checklist
Make sure that all packing material is removed from the supply may make it necessary to adjust the burners. The grill including the burner tie-down straps. flames of the burners should be visually checked. DO NOT SMOKE WHILE LEAK TESTING. Flames should be blue and stable with no yellow tips, excessive noise or lifting. -
Page 19: Operating Instructions
LP tank. Always keep your face and body as far from the grill as possible when lighting. Your Charmglow grill has an exclusive patented built-in ignition. The igniter is built in to the valve. To ignite each burner simply push and turn the control knobs to... -
Page 20: To Match Light The Grill
TO MATCH LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible. -
Page 21: Using The Side Burner
USING THE SIDE BURNER WARNING: IMPORTANT! counterclockwise to the “HI” position. If the burner does USING THE SIDE BURNER: not light, turn the control knob to “OFF”. If the smell of Inspect the gas supply hose prior to turning the gas gas is detected and the igniter is not functioning, “ON”. -
Page 22: Care And Maintenance Of The Side Burner
CARE & MAINTENANCE OF SIDE BURNER BURNER CLEANING: Clean the exterior of the burner with a wire brush. Clear any clogged burner ports with a straightened paper clip. Never enlarge the burner ports. Never use a wooden toothpick as it may break off the clog the port. STAINLESS STEEL: There are many different stainless steel cleaners available. -
Page 23: Exploded View
720-0036-HD-05 Exploded View... -
Page 24: Parts List
MODEL 720-0036-HD-05 PARTS LIST PART (DESCRIPTION) Q' TY PART (DESCRIPTION) Q' TY Lid, Front Gas valve, side burner Heat indicator 1 ‡ Bottom panel Heat insulating spacer 25A/B Double layer door (L&R) Handle assembly, post Main burner Handle assembly, lid... -
Page 25: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or well done, is affected to a large degree by the thickness of the To get the juiciest meats, add seasoning or salt after the cut. Expert chefs say it is impossible to have a rare cooking is finished on each side and turn the meat only doneness with a thin cut of meat. -
Page 26: Grill Cooking Chart
GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS VEGETABLES Slice. Dot with butter or margarine. Wrap in heavy-duty foil. Fresh Grill, turning occasionally. Beets Medium 12 to 20 minutes Carrots Grill, turning once. Brush occasionally Turnips with melted butter or margarine. - Page 27 WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS Tenderloin, Porterhouse, T-Bone, Sirloin Remove excess fat from edge. Slash remaining fat at 2-inch intervals. Rare 1 inch High 8 to 14 minutes Grill, turning once. 1-1/2 inch High 11 to 18 minutes Medium...
- Page 28 WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS FISH AND SEAFOOD Grill, turning once. Brush withmelted butter, margarine or oil Steaks to keep moist. Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Salmon High Swordfish Whole...
-
Page 29: Grill Recipe Suggestions
GRILL RECIPE SUGGESTIONS BBQ SALMON salad, dressed with vinaigrette ¼ c. cider vinegar flavored with fresh dill. 3 tbs. chopped parsley 2 large salmon steaks 1 tbs. vegetable oil BARBECUED LONDON 2 tbs. Oil 1 tbs. Worcestershire sauce Salt & pepper BROIL ½... - Page 30 VEGETABLE KABOBS ½ lb. boneless loin of lamb cut into CHICKEN TANDOORI STYLE 1” cubes 2/3 c. water, divided 3 medium-sized zucchini 8 large chicken thighs or ¼ c. chopped onion 12 cherry tomatoes drumsticks 2 tbs. soy sauce 12 fresh mushrooms 1 c.
- Page 31 PORK ROAST Apple cider vinegar basting sauce: 1 c. apple cider vinegar 6 oz. water ½ stick butter Salt, pepper, parsley and garlic seasoning 2 oz. lemon juice 10 lbs. pork roast Time: 1-1/2 hours to 2 hours Bring pork to room temperature before placing it on the spit rod.
-
Page 32: Limited Warranty
LIMITED WARRANTY MODEL 720-0036-HD-05 STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries Inc. warrants to the original consumer purchaser of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. This warranty excludes grills used in rental or commercial applications.
