- Page 1 STAINLESS STEEL GAS GRILL USE AND CARE GUIDE MODEL NO.: 730-0230 FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE.
-
Page 2: Table Of Contents
TABLE OF CONTENT SECTION ONE SECTION THREE Importance………………………….………….. 1 Care and maintenance…………………..…17 Precautions…………………………. ………. 2-3 Care and maintenance of the side burner….18 Placement of the grill……………….……….….3 Trouble shooting………………………..…18 SECTION TWO SECTION FOUR Screw description……………………………….4 Assembly Instructions……………………… 5-10 Exploded View……….…………………..19 Installation of the hose onto the NG regulator…11 Parts List…………………………………. -
Page 3: Importance
IMPORTANCE * * * WARNING * * * FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open lid 4. If odor continues, immediately call your gas supplier or your fire department. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 4: Precautions
PERSONAL INJURY Use a covered hand when opening the grill lid. Never lean over an open grill. When properly cared for, your 730-0230 (Charmglow) Grill will give safe, reliable service for many years. WHEN LIGHTING A BURNER, ALWAYS PAY However, extreme care must be used since the grill CLOSE ATTENTION TO WHAT YOU ARE DOING. -
Page 5: Placement Of The Grill
GRILL. mounted correctly for safe operation. The 730-0230 (Charmglow) Grill is designed for Clean the grill with caution. Avoid steam burns; do not optimum performance without the use of briquettes. Do use a wet sponge or cloth to clean the grill while it is hot. -
Page 6: Screw Description
Screw description Description(SCALE 1:1) Specification Quantity Item crossed flat head screw 12pcs 1/ 4× 38mm crossed flat head screw 1/4 × 12mm 20pcs double-ended screw 2pcs φ 4× 12 +3+ φ 5 × 12mm crossed tray head screw 1/4 × 10mm 2pcs landfrom screw 1pcs... -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY AND FOLLOW STEP BY STEP. Attention: Please lock the caster during the process of installation of the grill. TOOLS REQUIRED: Philips head screwdriver(not provide), Crescent wrench(not provide) Step 1: Assemble two regular casters to the right side panels and caster with brakes on the left side panel as shown figure below.. Step 2: : Assemble bottom panel to side panels with eight (8) 1/4x38 mm screws as shown figure below... - Page 8 Step 3: Assemble the back panel to the two sides panel. with four (4) 1/4x12mm screws as shown figure below. Step 4: Assemble the cart flame to the front side of the side panel with four (4) 1/4x38mm screws . Please attention Don’t screw them too tight in the beginning...
- Page 9 : Remove the head unit of grill from carton. Insert the upper portion of the grill onto the cart from Step5 the top with four (4)1/4x12mm screws. Caution!! The firebox is heavy, and we recommend two or more people to lift up firebox. : 1.Place flame tamers (3) on to the fire box as show figure below.
- Page 10 :.Use four (4)1/4x12mm screws to install the rear panel as show below. Step 7 : Assemble side burner with (8) 1/4x12mm screws as figure show below. Step8 Connect the condiment tray and side shelf with two screws. The two screws have been fitted in side shelf.
-
Page 11: Assembly Instructions
ASSEMBLY INSTRUCTIONS Side burner valve assembly: Step 1: Insert valve assembly through side Step 2: Remove 4(four) screws & washers panel from the “U” brackets on the side burner (Side panel, right #18B) Valve Step 3: Insert valve stem assembly into burner Step 4: Insert valve stem assembly through knob venturi hole to the control panel... - Page 12 First assemble the door handle to the door with the screw which packaged in the condiment rack Step 9: then assemble the two front doors to the grill with two (2) double ended screws. :Assemble the condiment rack inside of the left door. Step 10...
-
Page 13: Installation Of The Hose Onto The Ng Regulator
INSTALLATION OF THE HOSE ONTO THE NG REGULATOR Remove 3/8 inch adaptor Attach the hose Step1: Step2: The complete assembled unit Step 3: Note: You must remove the 3/8 inch adaptor first, in order to connect with the NG regulator. If you have any questions please contact our customer service:1-800-913-8999. -
Page 14: Your Gas Grill Is Ready To Use
Your gas grill is ready to use... -
Page 15: Gas Hook Up
Any replacement pressure propane use. regulator and hose assembly must be specified by the Total gas consumption (per hour) of the 730-0230 grill manufacturer. (Charmglow) Grill with all burners on “HI”: This is a natural gas configured grill. Do not Main burners 36,000 Btu/hr. -
Page 16: Installer Final Checklist
INSTALLER FINAL CHECK LIST Specified clearance maintained 24” from Unit tested and free of leaks. combustibles. User informed of gas supply shut off valve location. All internal packaging removed. Knobs turn freely. USER, PLEASE RETAIN THESE INSTRUCTIONS Burners are tight and sitting properly on orifices. FOR FUTURE REFERENCE. -
Page 17: Operating Instructions
Always keep your face and body as far from the grill as possible when lighting. Your Charmglow grill has an exclusive patented built-in ignition. The igniter is built in to the valve. To ignite each burner simply push and turn the control knobs to the HI setting, you will hear the valve click as it sends a spark to the pilot flame. - Page 18 TO MANUALLY LIGHT THE GRILL If the burner will not light after several attempts then the burner can be match lit. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible.
-
Page 19: Using The Side Burner
USING THE SIDE BURNER WARNING: IMPORTANT! counterclockwise to the “HI” position. If the burner does USING THE SIDE BURNER: not light, turn the control knob to “OFF”. If the smell of Inspect the gas supply hose prior to turning the gas gas is detected and the igniter is not functioning, “ON”. -
Page 20: Care And Maintenance Of The Side Burner
CARE & MAINTENANCE OF SIDE BURNER BURNER CLEANING: Clean the exterior of the burner with a wire brush. Clear any clogged burner ports with a straightened paper clip. Never enlarge the burner ports. Never use a wooden toothpick as it may break off the clog the port. STAINLESS STEEL: There are many different stainless steel cleaners available. -
Page 21: Exploded View
Exploded View for 730-0230... -
Page 22: Parts List
MODEL 730-0230 PARTS LIST PART (DESCRIPTION) Q'TY PART (DESCRIPTION) Q'TY Lid, Front Gas valve, side burner Heat indicator Bottom panel 25A/B Double layer door (L&R) Heat insulating spacer Handle assembly, post Main burner Handle assembly, lid Flame tamer Name plate... -
Page 23: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or well done, is affected to a large degree by the thickness of the To get the juiciest meats, add seasoning or salt after the cut. Expert chefs say it is impossible to have a rare cooking is finished on each side and turn the meat only doneness with a thin cut of meat. -
Page 24: Grill Cooking Chart
GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS VEGETABLES Slice. Dot with butter or margarine. Wrap in heavy-duty foil. Grill, turning occasionally. Fresh Beets Medium 12 to 20 minutes Carrots Grill, turning once. Brush occasionally Turnips with melted butter or margarine. - Page 25 WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS Tenderloin, Porterhouse, T-Bone, Sirloin Remove excess fat from edge. Slash remaining fat at 2-inch intervals. Rare 1 inch High 8 to 14 minutes Grill, turning once. 1-1/2 inch High 11 to 18 minutes Medium...
- Page 26 WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS FISH AND SEAFOOD Grill, turning once. Brush withmelted butter, margarine or oil Steaks to keep moist. Halibut 3/4 to 1 inch Medium to 8 to 15 minutes Salmon High Swordfish Whole...
-
Page 27: Grill Recipe Suggestions
GRILL RECIPE SUGGESTIONS butter and sprinkled with chopped BBQ SALMON parsley and a crisp lettuce salad. BARBECUED LONDON 2 large salmon steaks BROIL 2 tbs. Oil Note: Substitute catfish, halibut or Salt & pepper cod for salmon. 4 to 6 servings 2 oz. - Page 28 minutes longer or until potatoes Serve 4 chop eggplant finely. Add all the are tender. Let stand 5 minutes ½ lb. boneless sirloin or beef cut seasonings. Chill thoroughly and before serving. into 1” cubes serve on toast. ½ lb. boneless loin of lamb cut into VEGETABLE KABOBS 1”...
- Page 29 accordion pleated. Fasten the second meat hook into the rack. Turn your rotis burner on high. Rotis for 50 minutes or until done. PORK ROAST Apple cider vinegar basting sauce: 1 c. apple cider vinegar 6 oz. water ½ stick butter Salt, pepper, parsley and garlic seasoning 2 oz.
-
Page 30: Limited Warranty
LIMITED WARRANTY MODEL 730-0230 STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries Inc. warrants to the original consumer purchaser of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. This warranty excludes grills used in rental or commercial applications.
