EPOX KP6-LA Instructions Manual

A pentium ii processor based agp motherboard
Hide thumbs Also See for KP6-LA:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
KP6-LA
KP6-LA
KP6-LA
KP6-LA
KP6-LA
A Pentium
A Pentium
A Pentium
A Pentium
A Pentium
AGP motherboard
TRADEMARK
All products and company names are trademarks or
registered trademarks of their respective holders.
These specifications are subject to change without
notice.
II Processor based
II Processor based
II Processor based
II Processor based
II Processor based
® ® ® ® ®
Manual Revision 1.2
August 15, 1997

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP6-LA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EPOX KP6-LA

Summary of Contents for EPOX KP6-LA

  • Page 1 KP6-LA KP6-LA KP6-LA KP6-LA KP6-LA A Pentium A Pentium II Processor based II Processor based A Pentium A Pentium A Pentium II Processor based II Processor based II Processor based ® ® ® ® ® AGP motherboard TRADEMARK All products and company names are trademarks or registered trademarks of their respective holders.
  • Page 2 Supports (3) 16 bit ISA slots, (4) 32 bit PCI slots, (1) AGP slot and provides (2) independent high performance PCI IDE interfaces capable of supporting PIO Mode 3/4 and Ultra DMA 33 devices. The KP6-LA supports (4) PCI Bus Master slots and a jumperless PCI INT# control scheme which reduces configuration confusion when plugging in PCI card(s).
  • Page 3 Features KP6-LA • KP6-LA utilizes a Lithium battery which provides environmental protection and longer battery life. • Supports the Universal Serial Bus (USB) connector. The onboard PIIX4 chip provides the means for connecting PC peripherals such as; keyboards, joysticks, telephones, and modems.

  • Page 4: Kp6-La Detailed Layout

    Installation KP6-LA KP6-LA Detailed Layout Mou s e ATX Pow er Input (Top) PS/ 2 Ke yboa r d (Bottom ) Pow e r Su pply USB 1 Fa n Mon itor in g (Top) CP U Fa n P ow er...

  • Page 5: Easy Installation Procedure

    KP6-LA Installation Easy Installation Procedure Easy Installation Procedure The following must be completed before powering on your new system: Configure Jumpers to match your hardware Install memory chips Device Connectors Configure Jumpers designs all motherboards with the fewest jumpers to make your install fast 2theMax and easy.
  • Page 6 Installation KP6-LA CPU Processor Selection JP8: = 1-2 - 200MHz = 3-4 - 233MHz (Default) JP8: = 5-6 - 266MHz = 7-8 - 300MHz = 9-10 - 330MHz = 11-12 - Reserved = 13-14 - Reserved = 15-16 - Disable E.S.S.J.

  • Page 7: System Memory Configuration

    System Memory Configuration Memory Layout The KP6-LA supports (3) 168-pin DIMMs (Dual In-line Memory Module) and (4) 72-pin SIMMs (Single In-line Memory Module). The DIMMs can be either EDO (Enhanced Data Out) or SDRAM (Synchronized DRAM). The 72-pin SIMMs must be installed in pairs, and DIMMs may be installed using just one chip.
  • Page 8 Installation KP6-LA * SDRAM only supports 8, 16, 32, 64, 128MB DIMM modules. Table 1 Page 8...

  • Page 9: Device Connectors

    KP6-LA Installation Device Connectors Please install the motherboard into the chassis. Now that your motherboard is installed you are ready to connect all your connections (figure 12). 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6...
  • Page 10 Installation KP6-LA Device Connectors (continued) Power On/Off IDE LED indicator - LED ON when Onboard PCI IDE Hard disks is activate Power Saving LED indicator - LED ON when system is in any power saving mode Sleep/Resume switch : Closed to enter sleep mode, a keystroke or mouse movement will instantly "wake up"...
