Summary of Contents for GMC TTS5000M
- Page 1 1400W TILE AND TRIM CIRCULAR SAW TTS5000M INSTRUCTION MANUAL Black Magenta Code: TTS5000M Cyan Yellow Date: 070206 Edition: 13 Op: DCR...
-
Page 2: Table Of Contents
Contents Warranty Introduction Environmental protection Description of symbols Specifications General safety rules Additional safety rules for laser lights Additional safety rules when using water cooling system Additional safety rules for tile and timber cutting saws 6 Testing your safety switch Accessories Unpacking Assembly... -
Page 3: Introduction
1. Do not attempt to change the position of the laser under any circumstances, it has been set at the factory and is accurately focused on the centre of the saw blade. 2. It may be more difficult to see the laser line in conditions of bright sunshine and on certain surfaces. -
Page 4: General Safety Rules
General safety rules WARNING. Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains operated (corded) power tool or battery operated (cordless) power tool. -
Page 5: Additional Safety Rules For Laser Lights
4. Power tool use and care a. Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b. -
Page 6: Additional Safety Rules When Using Water Cooling System
• Keep hands away from cutting area and blade. Keep your second hand on the auxiliary handle, or motor housing. If both hands are holding the saw, they cannot be cut by the blade. • Keep your body positioned to either side of the blade, but not in line with the blade. -
Page 7: Testing Your Safety Switch
• Always use blades with correct size and shape (diamond versus round) of arbour holes. Blades that do not match the mounting hardware of the saw will run eccentrically, causing loss of control. • Never use damaged or incorrect blade washers or bolts. - Page 8 • Maintain a firm grip with both hands on the saw and position your arms to resist kickback forces. Position your body to either side of the blade, but not in line with the blade.
-
Page 9: Accessories
Accessories The GMC TTS5000M Tile/Trim Saw is supplied with the following accessories as standard: • Residual Current Device (Fitted) • 125mm Diamond Turbocut Blade (Fitted) for wet tile/masonry cutting ONLY • 125mm 24-teeth TCT Blade for timber cutting ONLY •... -
Page 10: Know Your Product
Know your product 1. Laser light assembly 2. Trigger switch 3. Lock off button 4. Laser light on/off button 5. Motor housing 6. Main handle 7. Front handle 8. Bevel adjustment lever 9. Bevel scale 10. Parallel fence locking knob 11. -
Page 11: Overview
By loosening the bevel adjustment lever (8), the body and the blade of the saw can be tilted to any angle up to 45° for making angle cuts. Please note that the maximum depth of cut is reduced when cutting at an angle. -
Page 12: Using The Water System
(Fig. N). 3. Hold the base plate flat against the edge of the work piece and lift the body of the saw until the blade is at the right depth (Fig. O & P). Use the depth of cut indicator... -
Page 13: Adjusting The Bevel Angle
(2) (Fig. T). Once the saw has started there is no need to hold the lock off button depressed. 3. When you release the trigger switch (2), the saw turns off. 4. To restart, it is necessary to again first depress the lock off button. -
Page 14: Making A Cut
6. When making a cut always use steady, even pressure. Forcing the saw causes rough cuts and could shorten the life of the saw or cause kickback. Allow the blade and the saw to do the work. 7. After completing your cut, release the trigger switch and allow the blade to come to a complete stop. -
Page 15: Using The Parallel Fence
6. Always let the blade reach full speed (approximately 2 seconds) before you begin to cut into the workpiece. 7. Slowly lower the saw into the workpiece, using the front of the base resting on the workpiece as a hinge point. -
Page 16: Troubleshooting
3. Re-lubricate all moving parts at regular intervals. 4. If the body of the saw needs cleaning, wipe it with a soft damp cloth. A mild detergent can be used but nothing like alcohol, petrol or other cleaning agent. 5. Never use caustic agents to clean plastic parts. - Page 20 GMC customer assist If your product needs repairing, replacing, technical service or you simply need help or advice, please contact us on our Customer Assist Line 1300 880 001 (Australia) or 0800 445 721 (New Zealand). For prompt service we suggest you log your service request online at www.gmcservice.com.au.
