Page 1: Instruction Manual
INSTRUCTION MANUAL 2000W 250mm (10”) Table Saw with Laser Line Generator* * Patent Pending • Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris LS250TS 061004 ED8 DCR... -
Page 2: Table Of Contents
Tips to avoid kickback Making longitudinal cuts Cutting a narrow workpiece Cutting an extremely narrow workpiece Making bevel cuts Making cross cuts Replacing the saw blade Changing the batteries of the laser generator Maintenance Power cord maintenance Cleaning General inspection ��������... -
Page 3: Introduction
Introduction Your new GMC power tool will more than satisfy your expectations. It has been manufactured under stringent GMC Quality Standards to meet superior performance criteria. You will find your new tool easy and safe to operate, and, with proper care, it will give you many years of dependable service. -
Page 4: Safety Rules For Laser Lights
Safety rules for laser lights The laser light/laser radiation used in the GMC REDEYE® system is Class 1 with maximum 1mW power and 650nm wavelengths. These lasers do not normally present an optical hazard, although staring at the beam may cause flash blindness. -
Page 5: Additional Safety Rules For Table Saws
Minimum cross-section: 1.0mm2. When a tool • Do not use or leave the saw in the rain and never use it in damp, humid, or wet conditions. Before using a tool, Prevent body contact... - Page 6 Check the power cord. Never use a faulty or damaged power cord. • If the cordset is damaged take the saw to an authorised service centre for repair or replacement • Never attempt any repairs yourself, always take it to an authorised service centre for repair or parts replacement.
-
Page 7: Unpacking
1. Remove all loose parts from the carton. 2. Remove the packing materials from around the saw. 3. Carefully lift the saw from the carton and place it on a level work surface. Required Tools The following tools (not supplied) are required to assemble and maintain the table saw •... -
Page 8: Components
Components The GMC LS250TS table saw is supplied with the following components: 1. Table saw 2. Riving knife and laser assembly 3. Blade guard 4. Wheels x2 5. Hubcaps x2 6. Rip fence 7. Mitre gauge 8. Push stick 9. Spanner 10. -
Page 9: Know Your Product
Know your product 1. Table top 2. On/off switch 3. Cable storage 4. Handle for tilting table saw (Upper) 5. Handle for tilting table saw (Lower) 6. Mitre gauge holder 7. Spare blade holder 8. Riving knife 9. Laser assembly 10. -
Page 10: Assembly
3. Fit the left hand side extension table into the 2 positioning holes on the left hand side of the table saw, the extension table locking knobs (28) may need to be loosened if it is a tight fit (fig B). -
Page 11: Attaching The Wheel Axle
2. Slide the wheel axle through the holes in the 2 stand legs on the left hand side of the table saw (fig J). Attaching the wheels 1. Fit the flat washer (fig K) followed by the... -
Page 12: Fitting The Blade Guard
Using the mitre gauge holder 1. The table saw features a mitre gauge holder on the right hand side of the housing. 2. Slide the mitre gauge into the holder until it clicks into place and is secure in the holder (fig W). -
Page 13: Folding The Stand
(27). 3. Using the handle on the table saw (4) and the soft grip handle on the lower leg (5) gently tilt the table saw onto its left hand side so it is resting on the... -
Page 14: Switching On And Off
With the power disconnected, place a set square against the saw blade. Adjust the blade angle wheel until the blade is parallel to the set square then move the pointer to 0° on the blade angle scale. -
Page 15: Using The Mitre Gauge
Push sticks A push stick should always be used if your hand gets within 125mm (5”) of the saw blade. A push stick is a safety device that helps to keep your hands and fingers away from the saw blade. A handle helps to apply pressure... -
Page 16: Tips To Avoid Kickback
After each new adjustment it is advisable to carry out a trial cut in order to check the set dimensions. After switching on the saw, wait for the blade to reach its maximum speed of rotation before commencing with the cut. -
Page 17: Cutting An Extremely Narrow Workpiece
Worn push blocks must be replaced without delay. Making bevel cuts 1. Always use the fence when cutting bevels. 2. Set the saw blade to the required angle using the blade angle wheel (21). 3. Set the fence to suit the width and height of the workpiece using the laser line as a guide. -
Page 18: Changing The Batteries Of The Laser Generator
(refer to the arrow on the saw blade). 10. Re-fit and re-set the riving knife and the saw blade guard. 11. Before using the saw again, check that all safety devices are in good working order. - Page 20 GMC Customer Assist If your product needs repairing, replacing, technical service or you simply need help or advice, please contact us on our Customer Assist Line 1300 880 001 (Australia) or 0800 445 721 (New Zealand). For prompt service we suggest you log your service request online at www.gmcservice.com.au.
