2400W
355mm (14")
Cut Off Saw
2 Y
W
2 Y
W
EAR
ARRANTY
EAR
ARRANTY
30 D
30 D
M
M
AY
AY
ONEY
ONEY
B
G
B
G
ACK
UARANTEE
ACK
UARANTEE
P L A T I N U M
M X 3 5 5 C
• Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris
Black
Magenta
Cyan
Yellow
Code: MX355C
Date: 060105
Edition: 04
Op: DCR
Advertisement
Table of Contents
Related Manuals for GMC MX355C
Summary of Contents for GMC MX355C
- Page 1 M X 3 5 5 C • Melbourne • Perth • Auckland • Hong Kong • Shanghai • Taipei • New York • Verona • London • Paris Black Magenta Cyan Yellow Code: MX355C Date: 060105 Edition: 04 Op: DCR...
-
Page 2: Table Of Contents
Attaching the rear spark shield Adjusting the vice Adjusting the cutting angle Adjusting the fence Turning on and off Replacing a cut off disc Operation Some helpful tips when using the chop saw Maintenance Cleaning General inspection ARRANTY ARRANTY 30 D... -
Page 3: Introduction
Dear customer If you require any help with your product, whether it is a Warranty claim, spare part or user information, please phone our Help Line for an immediate response. Phone 1300 880 001 in Australia or 0800 445 721 in New Zealand. -
Page 4: General Safety Instructions
General safety instructions To use this tool properly, you must observe the safety regulations, the assembly instructions and the operating instructions to be found in this Manual. All persons who use and service the machine have to be acquainted with this Manual and must be informed about its potential hazards. -
Page 5: Additional Safety Rules For Cut Off Saws
RPM value stated on the tool. • Check the cut off disc before mounting it into the saw. Strike the disc with a wooden handle whilst balancing the disc on your finger. Listen for the ring. If the tone is dull, do not use the disc. -
Page 6: Accessories
Always remove the plug from the mains socket before making any adjustments or maintenance, including changing the disc. Accessories The GMC MX355C chop saw is supplied with the following accessories as standard 1. 8mm Hex key 2. 5mm Hex key 3. -
Page 7: Know Your Product
Know your product 1. Trigger switch 11. Vice lock release lever 2. Lock-off button 12. Vice handle 3. Disc guard 13. Vice 4. Front spark shield 14. Fence 5. Spark shield locking knob 15. Carry handle 6. Cut off disc 16. -
Page 8: Overview
Overview The cut off saw is used for cutting steel such as pipe, box section, rectangular, angle iron and steel bars. The saw can cut at angles from 0° to 45° left and right, it features a three position fence that permits an extended cutting range. -
Page 9: Adjusting The Vice
Adjusting the vice The vice can be adjusted quickly by loosening the vice lock release lever and pushing forward. 1. Place your workpiece in between the fence and vice. 2. Lift the vice lock release lever to the left and push the vice forward (fig H). -
Page 10: Turning On And Off
Replacing a cut off disc CAUTION. Always ensure that the saw is switched off and unplugged from the power supply before installing or removing a disc. 1. Loosen and remove the spark shield locking knob (fig O). -
Page 11: Operation
7. Once the cut is finished, raise the arm to clear the disc from the workpiece, release the trigger and the cut off saw will stop. Please note that the disc will continue to turn for a few revolutions even though the saw is switched... -
Page 12: Some Helpful Tips When Using The Chop Saw
5. Remove the metal that may have built up around the guard and spark deflector. CAUTION. Do not use cleaning agents to clean the plastic parts of the saw. A mild detergent on a damp cloth is recommended. General inspection Regularly check that all the fixing screws are tight. They... -
Page 16: Year Warranty
Carefully read the entire Instruction Manual before using this product. Before returning this product for a Warranty Claim or any other reason Please Call 1300 880 001 (Australia) or 0800 445 721 (New Zealand) When you make your call, please have the following information at hand: •...
