MODEM-CN Connector
Front Audio Connector
CD-IN Connector
4Mbit Flash ROM BIOS
IrDA Connector
CNR Expansion Slot
32-bit PCI Expansion Slot x5
AGP Pro Expansion Slot
Front Panel Connector
A
GP Pro External Power
Connector
JP7 Raid Select Jumper
(Optional)
ATA/100
IDE RAID
Connector x2 (Optional)
FDD Connector
JP14 CMOS Clear Jumper
nd
Supports 2
USB
Connector
FAN2 Connector
Chassis Intrusion Detector
Motherboard Map
15
O
n
l
i
n
e
M
a
n
u
a
l
O
n
l
i
n
e
M
a
n
u
a
l
PC99 Colored Back Panel
with 10/100Mbps Ethernet
RJ45 Connector(Optional)
Resettale Fuse
4-pin 12V ATX Power
Connector
CPU Fan Connector
478-pin CPU socket with
Voltage and Frequency
Auto-detection that supports
®
®
Intel
Pentium
1.30~1.50GHz+ CPU
Low ESR Capacitors
184-pin RIMM Socket x4
supports PC-600/800
RDRAM maximum up to
2GB
®
Intel
850 chipset with MCH,
ICH2X and FWH that
supports LAN, Ultra ATA/100,
RDRAM Solution
FAN3 Connector
ATX Power Connector
ATA33/66/100 IDE
Connector x2
4
