- Page 1 Designer Island Hood • DIH900 Installation & User’s instructions...
-
Page 4: General Information
• Your new Belling Island Hood Dear Customer These instructions are designed to help you know your new cooker hood quickly and to achieve the best possible results. It is most important that this instruction book should be retained with the appliance for future reference. -
Page 5: Installation Instructions
type. If other types of flue or appliances are fitted, ensure there is adequate ventilation in the room. All installations must comply with local authority requirements for the discharge of exhaust air. • Positioning When installed above a cooking appliance the distance between the surface of the appliance hotplate and the lower grill of the hood must not be less than 65cm (25½”). -
Page 6: Electrical Connection
Note: Depending on the location and the construction of ceiling, it may be necessary to use a more substantial method of fixing, e.g. nuts and bolts, rather than normal self-tapping or wood screws. B) Mount the connector flange F above the cooker hood ventilation kit, using the G screws (Fig. - Page 7 1A) LUMINOUS A = LIGHT B = OFF C = SPEED I D = SPEED II E = SPEED III F = AUTOMATIC STOP TIMER - 15 minutes The “Automatic stop timer” allows the hood to continue functioning for 15 minutes at the operating speed set at the time this function is activated.
- Page 8 Do change charcoal filters regularly Don’t leave naked flames under the cooker hood Don’t leave frying pans unattended during use as overheated fat may catch fire Don’t flambé cook under the cooker hood Don’t try to check the filters when the hood is in operation. Don’t touch the lamp after prolonged use of the appliance.
-
Page 9: Optional Extras
Optional extras • Please quote the following part number if you require a ducting or tall ceiling kit. Filter Ducting Kit Short Ducting Kit Long Tall ceiling kit Stainless Steel Tall ceiling kit Aluminium • Calling for Service Please contact your retailer in the first instance. If you experience difficulty contact Belling Appliances (After Sales Division) Remember that you may be charged for the visit (even during the guarantee period) if nothing is found to be wrong with the appliance, so always check the instructions in case... - Page 12 Belling Appliances Ltd Stoney Lane, Prescot, Merseyside L35 2XW PART No. DIH900001/01/02...
