- Page 1 COOKER HOOD INSTRUCTON MANUAL Read this manual carefully before operation Pictures in this manual are for reference only, the product in kind pre BSO60...
- Page 2 Information and advice This unit should be installed by a qualified technician, please retain your certificate of compliance. In certain circumstances electrical appliance may be a danger hazard. A) There shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels.
- Page 3 This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 4 U) Regarding the instructions for the blub replacement, thanks to refer to the section “Replacing Bulb”. Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The appliance can only be used over a 4 element hob at most. CAUTION: Accessible parts may become hot when used with cooking appliance.
- Page 5 Installation Ensure the power has been turned off before beginning this installation. Plug must be assembled in places easy to drag and insert . To install this hood you will require two assistants. You will need the following tools and material to complete this installation: *Drill*Flat head screwdriver *Phillips head screwdriver or cordless drill and Phillips head bit*Tin snip*...
- Page 6 Method 1 1. According to the figure, make sure the position of hood in the cabinet. The wood strips should be line up with the 4 keyholes slots on the top of the range hood. On the cabinet, install 4 screws (supplied) according to the relative position of 4 key holes on the bottom of hood.
- Page 7 Method 2 In the installation surface in cabinet don’t adapt to install the cooker hood, then as per fig, fix the position of cooker hood on the wall. On the wall, install 2 screws(supplied) according to the relative position of 2 key holes on the back of hood.
- Page 8 Check valve Installation Hold on check valve with your hands, align the box gap, put in the check valve , and then spin to a certain angle until three angl es of the valve are stuck. Installation is complete. Carbon Filter Activated carbon filter can be used to trap odours Normally the activated carbon filter should be changed at three or six month s...
- Page 9 Hood Using Method Operation Check beforehand Check the safe condition of the appliance - Check whether there are visible defects. - Check that all parts of the appliance have been securely fitted. Switching on/off - Slide the front part of the cooker hood. ·...
-
Page 10: Cleaning Instruction
Clean ventilation fans frequently. Grease should not be allowed to accumulate on fan or filter. Cleaning Instruction Disconnect range hood from power supply before cleaning or servicing. 1. Cleaning the surface of hood frequently. Use mild soap or detergent to clean the hood. 2. - Page 11 It is recommended to clean the metallic filter every three months by carrying out the following instruction: —Remove the metallic filter from the cooker hood and wash it in a solution of water and neutral liquid detergent, leaving to soak —Rinse thoroughly with warm water and leave to dry.
- Page 12 The manufacturer shall decline all responsibility if the foregoing recommendations and instruction regarding installation, maintenance and use are not observed and respected when using the cooker hood. Glen Dimplex Australia Pty Ltd 1340 Ferntree Gully Road Scoresby 3179 1300 556 816 FAX: 1800 058 900 Glen Dimplex New Zealand Ltd 38 Harris Road...
