ADF PAPER CHUTE INSTALLATION

2.
1. Raise the document cover to about 45 degrees.
2. Place the ADF paper chute to about 45 degrees. Insert the ADF
paper chute to auto feeder holes on the document cover as shown
in Figure 2-4.
3. Pull out the wire leg under the paper chute.
4. Pull out the paper chute extension to the length you wish.
Figure 2-4 Install the ADF paper chute
ADF Paper Chute
2-5
Paper Chute
Extension
Document
Cover
