User's Manual
Plus
Plus
Plus
For AV810C
/AV820C
/AV830C
Document Imaging Scanner
Doc. No. 250-0332-E V1.0
Avision Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV810CPlus and is the answer not in the manual?

Questions and answers

Related Manuals for Avision AV810CPlus

Summary of Contents for Avision AV810CPlus

  • Page 1 User’s Manual Plus Plus Plus For AV810C /AV820C /AV830C Document Imaging Scanner Doc. No. 250-0332-E V1.0 Avision Inc.
  • Page 2 Avision Inc. Material scanned by this product may be protected by governmental laws and other regulations, such as copyright laws, the customer is...
  • Page 3 Warranty The information contained in this document is subject to change without notice. Avision makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of fitness for a particular purpose. Avision shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

  • Page 4: Fcc Radio Frequency Interference Statement

    Safety Regulation UL1950, Third edition EN 60950 IEC 60950 FCC Part 15 Subchapter J Class B EMI Regulation DOC Class B (Canada) Responsible Party: Avision Labs, Inc. Telephone No.: +1 (510) 739-2369...

  • Page 5: Table Of Contents

    4. SCANNER OPERATION..........4-1 4.1 STARTING YOUR FIRST SCAN FROM WITHIN A TWAIN OR A PLUG- IN APPLICATION ..................4-1 4.2 USING AVISION SCANNER DRIVER USER INTERFACE ..... 4-5 4.2.1 CHOOSING YOUR SCANNING SOURCE........4-5 4.2.2 DETERMINING YOUR RESOLUTION........4-6 4.2.3 SELECTING A PROPER IMAGE TYPE ......... 4-8 4.2.4 ENHANCING YOUR IMAGE ..........4-13...
  • Page 6 5. CARE AND MAINTENANCE........... 5-1 5.1 CLEANING THE ADF .............. 5-1 5.2 CLEANING THE GLASS ............5-3 5.3 REPLACING THE ADF DETACHABLE PAD MODULE ......5-4 6. TROUBLESHOOTING..........6-1 6.1 FREQUENTLY ASKED QUESTIONS..........6-1 6.2 PAPERJAM IN THE ADF............6-4 6.3 TECHNICAL SERVICE..............

  • Page 7: Introduction

    INTRODUCTION Congratulations on your purchase of the Avision document scanner. Avision is one of the leading company to make high quality document scanner. To ensure the optimum performance of the scanner, please take a few minutes to read through this manual before you install and operate the new scanner.
  • Page 8 Power Adapter Power Cable SCSI Cable Output Paper Tray User’s Manual, Software CD SCSI Card Scanner main unit Cushion Carton Figure 1-1 Scanner Package...

  • Page 9: Scanner Installation

    SCANNER UNPACKING Please unpack the scanner carefully. If any item is missing or damaged, please contact your authorized Avision dealer immediately. Remove the shipping retainer: 1. Place the scanner on its side as shown to reveal the shipping retainer as shown in Figure 2-1.
  • Page 10 “Shipping Position” Figure 2-1 Remove the shipping retainer. “Use Position” Figure 2-2 Fasten the shipping retainer.
  • Page 11 Refit the shipping retainer: Whenever you need to transport the scanner, please follow the instructions below: 1. Turn off the scanner. 2. Raise the document cover. You can see clearly the flatbed glass as well as the reading engine. 3. Turn on the scanner. At this moment, the reading engine will move a few inches forward and stay there for a few seconds.
  • Page 12 SCSI ID Selector SCSI Terminator Switch Figure 2-3 SCSI ID setting/Terminator switch...

  • Page 13: Adf Paper Chute Installation

    ADF PAPER CHUTE INSTALLATION 1. Raise the document cover to about 45 degrees. 2. Place the ADF paper chute to about 45 degrees. Insert the ADF paper chute to auto feeder holes on the document cover as shown in Figure 2-4. 3.
  • Page 14 ADF output paper rack installation Hold the output paper rack some 30 degrees as shown in Figure 2-5. Insert the three clasp-joints on the output paper rack in their respective places on the ADF. Release the paper rack gently. Make sure the rack is firmly attached to the ADF.

  • Page 15: Document Loading

    DOCUMENT LOADING For flatbed scanning, see Figure 2-6. Document Cover Reference Mark Original Document Glass Reference Frame Figure 2-6 Lay the paper on the scanner...
  • Page 16 Standard paper size should feed easily through the scanner. To prevent occasional paper jam when automatically feeding multiple documents, loosen the paper before loading(See Figure 2-7). Left Guide Balance Wire Document Right Guide Figure 2-7 Use ADF to load multiple documents...

  • Page 17: Connecting The Cables

    CONNECTING THE CABLES Be sure the scanner power is switched off. Connect the power cable and signal cable as Figure 2-8 and Figure 2-9. Turning on the Power The power is controlled by a toggle switch on the side of the scanner.
  • Page 18 Power Switch SCSI Port SCSI Cable Connector Power Cable SCSI Device B To PC SCSI Port To Power Outlet Figure 2-8 Cable connection 2-10...

  • Page 19: Installation Of The Scsi Card

    INSTALLATION OF THE SCSI CARD 6.1 PC USERS 6.1.1 ADAPTEC SCSI CARD Hardware Installation Turn off your computer. Plug the SCSI card in an available slot of your computer. Be sure to screw it firmly. Turn on your computer. Software Installation Windows 3.1 If your scanner comes with an Adaptec AVA-1505Ae, then the installation of the SCSI card driver will be complete during the installation of the...

  • Page 20: Mac User

    Windows NT 4.0 Press Start>Setting>Control Panel. And choose “SCSI Adapter” from the Control Panel menu. The “SCSI Adapter” dialog box is displayed. Choose Driver. Choose “Add” and “Select manufacturer and SCSI adapter”. Select “Adaptec” as the manufacturer and “AIC-6X60 ISA Single Chip SCSI Controller”...

  • Page 21: Scanner Driver Installation

    OmniPage, PhotoShop, etc. Insert “ Avision Driver Kit” disk into your floppy disk drive. The Avision Driver Kit X.x.x dialog box as Fig. 3-1 will appear. Read "Read Me First" for some valuable information which you should note.
  • Page 22 A dialog box as Figure 3-4 will appear on the screen. Select the “Avision Scan” icon, ignore the “Scanner Model” list and the “Set SCSI ID” button, The list of scanner model will be displayed. Click on the "Set SCSI ID" button. The "Scanner ID" window as Fig.
  • Page 23 Figure 3-5 Scanner ID You can find the latest driver in our homepage located at the Note: World Wide Web(WWW) with the web site: http://www.avision.com...

  • Page 24: Pc Users

    A Microsoft Windows-compatible pointing device (e.g., the mouse); A CD-ROM drive. Installation procedures of Avision Scanner driver are as follows: Start Windows 3.1, Windows 95, Windows 98 or Windows NT 4.0. Insert Avision PaperCom Supreme CD to your CD-ROM drive.
  • Page 25 2.2 WINDOWS 95/WINDOWS 98/WINDOWS 2000 OR WINDOWS NT4.0 Press the Start button and choose RUN. Type d:\driver\scsi.exe (d means the letter indicating your current your CD-ROM drive). Choose O.K. Follow the subsequent instruction on the screen to complete the instruction. (Normally just press OK and the installation will be completed.)

  • Page 26: Scanner Operation

    SCANNER OPERATION AV830C Plus allows you to operate the scanner from within a TWAIN or plug-in software application. As the scanner driver is not a stand-alone software, it has to be started from within a TWAIN*-compliant software application and then the scanner driver is able to scan and load the image to your computer.
  • Page 27 The Mac Plug-in user interface will pop up on the screen. Place the document upside down on the document glass with the text facing away from you. Click the Preview or Scan button to preview or scan your document or image. Figure 4-1 Mac Plug-in user interface *TWAIN : Stands for Technology Without An Interesting Name, an industry-standard protocol which exchanges information between...
  • Page 28 PC Users Open your application and choose Select Source from the File menu. If the Select Source command is not available from the File menu, see the user guide of your application to learn how the TWAIN link is used. A dialog box appears containing the different TWAIN sources for you to choose from to bring an image into your application.
  • Page 29 From the File menu, choose Acquire . Avision TWAIN user interface as Figure 4-2 will pop up on the screen. Click Preview or Scan button to scan the document. Figure 4-2 PC TWAIN user interface...

  • Page 30: Using Avision Scanner Driver User Interface

    USING AVISION SCANNER DRIVER USER INTERFACE 2.1 CHOOSING YOUR SCANNING SOURCE Two scanning sources are provided - flatbed as well as transparency. However, if you have not installed the transparency kit , please leave the source to the flatbed option.

  • Page 31: Determining Your Resolution

    2.2 DETERMINING YOUR RESOLUTION A good control of the resolution results a satisfactory detail of an image that scans. The resolution is measured by dots per inch(dpi). Normally, the greater the dpi number, the higher the resolution and the image file size.
  • Page 32 Tips: 1. For your information, an A4 size color image scanned at 300 dpi at True Color mode consumes approximately 25 MB of disk space. A higher resolution (usually means over 600 dpi) is recommended only when you need to scan a small area at True Color mode. 2.

  • Page 33: Selecting A Proper Image Type

    2.3 SELECTING A PROPER IMAGE TYPE Select image type through the mode from the scanner user interface for your own purpose. Please see Figure 4-4 as shown in below: Figure 4-4 Image Type...
  • Page 34 Each image type is described as follows: Line art LineArt presents the image in black and white only and there are no intermediate shades of gray in between. That means each pixel of the image is 100% black or 100% white. LineArt is the best choice of image type if you want to scan text, pen or ink drawing.
  • Page 35 Halftone In addition to the black and white display, Halftone simulates grayscale by using different size of dots. Particularly when you view the image at a certain distance, it looks very closely like a gray image yet it consumes the least disk space. Halftone is the picture that we usually see in newspapers or magazines.
  • Page 36 Gray (4096 levels gray scale/Internally) A single-channel image consists of at least 256 levels of shades of gray in an image. A 12 bits scanner produces a Gray image with 4096 shades of gray between pure black and pure white. Gray is the best choice of image if you wish to scan a black and white photograph.
  • Page 37 256 Colors The 256 colors image provides 256 levels of color hues. The disk space required to save an image in 256 colors is 1/3 of that required to save a 24-bit true color image. Figure 4-8 A 256 Color Image True Color A 36-bit Color image consists of three 12-bit color channels.

  • Page 38: Enhancing Your Image

    2.4 ENHANCING YOUR IMAGE Brightne s Contrast Gamma Highlight Shadow Intensity Saturation Adjusts the lightness or darkness of an image. Brightness: higher the value, the brighter the image. Decrease your Normal Increase your Brightness Brightness 4-13...
  • Page 39 Adjusts the range between the darkest and the lightest Contrast: shades in the image. The higher the contrast, the bigger the different gray scales. Decrease your Contrast Normal Increase your Contrast Adjusts the midtone of the image without losing details Gamma: of the lightest and the darkest areas.
  • Page 40 Highlight/Shadow: Highlight refers the lightest point in a scanned image while shadow refers the darkest point. Using Highlight and Shadow tool together allow you to extend the range of color and reveal more details in a gray or color image. Highlight: 255/Shadow: 0(Normal) Highlight: 210/Shadow:10 Highlight: 200/Shadow:0...
  • Page 41 Adjust the hue up to 360§ by clicking your desired Hue: color on the Color wheel or clicking the up or down arrow button. (Note the level of intensity for the color will be changed simultaneously when the hue adjustment is made). The Color Wheel Adjust the color strength by clicking the Up or Down Intensity:...
  • Page 42 Speed Mode Advance Settings Auto Crop Invert Image Color Matching Quality Mode Advance Settings: (PC) Click the button and a dialog box in below will be displayed. This dialog allows you to remove one of the R(Red), G(Green), or B(Blue) color channel while scanning.
  • Page 43 Your original with blue color After click the B(Blue) channel background Your original with red watermark After click the R(Red) channel [The watermark been removed] Note: SRGB: The SRGB function allows your scanned image to retain the same image quality among your scanning software, computer monitor, and printing output if both your computer monitor and printer support SRGB.
  • Page 44 The invert command reverses the brightness and the Invert Image: color in the image. For color images, each pixel will be changed into its complementary color at the command of Invert. Original After Invert 4-19...
  • Page 45 Color Matching: Adjusts the color quality of the image so that it comes close to that of the original. This function uses default parameters to adjust the image. Before Color Matching After Color Matching Quality/Speed Mode: Choose Speed Mode if you need to speed up your scanning task.
  • Page 46 Auto Level: (Mac) Automatically adjusts the highlight and shadow areas of the scanned image to give it an optimal effect. Before Auto Level After Auto Level Automatically sets the whole document as the scan Auto Crop: area, no matter what its size. Before Auto Crop After Auto Crop 4-21...
  • Page 47 Sharpens the scanned image. Look for more selections Sharpen: under this item. Original Extra Heavy 4-22...
  • Page 48 Eliminates the moire patterns* commonly found in Descreen: printed matter. Before Descreen After Descreen *Moire pattern: An undesirable pattern in a color printing resulting from incorrect screen angle of overprinting halftone. 4-23...

  • Page 49: Viewing The Image Tool

    2.5 VIEWING THE IMAGE TOOL Quick Zoom Select Scan Area Zoom Move Image Provide frequently used magnification ratios (1x, 2x, 4x, Quick Zoom: 8x, or view the whole image) to perform a quick enlargement of your preview image. Select Scan Area: Select your desired scan area.

  • Page 50: Other Tools

    2.6 OTHER TOOLS Rescale your Image Lock Image Width & Height Quick Choice Scan Size Unit Enlarge or reduce your image in a pre-set proportion Scale: (from 50% to 800%). Display current image width. Width: Display current image height. Height: A reminder of the m easuring system in use.

  • Page 51: Starting Final Scan

    2.7 STARTING FINAL SCAN Preview: Previews your image to allocate the area to be scanned. Scans the area with the parameters you have set . Scan: Cancels the current job. Exit: As shown in the figure below, in the Preview window, you can define the area to be scanned by dragging the cursor auxiliary lines with the mouse.

  • Page 52: Care And Maintenance

    CARE AND MAINTENANCE CLEANING THE ADF Your scanner is designed to be maintenance-free. However, it still needs to be cleaned occasionally to ensure optimum image quality and performance. The scanner parts may be contaminated with ink, toner particles or paper coatings. As a result, the scanner needs to be cleaned occasionally particularly in the following cases: 1.
  • Page 53 ADF Pad Module Feeding Roller · ¶ Figure 5-1 Opening the ADF unit.

  • Page 54: Cleaning The Glass

    CLEANING THE GLASS The procedures Soak a cotton swab with some isopropyl alcohol. (95%) Open the ADF unit and document cover as shown in Figure 5-2. Wipe the glass of flatbed and ADF area by moving the swab from side to side. Close the ADF unit and document cover.

  • Page 55: Replacing The Adf Detachable Pad Module

    REPLACING THE ADF DETACHABLE PAD MODULE After scanning approximately 150,000 pages through the ADF, the pad spring may be worn out and you may experience problems with document feeding. In this case, it is highly recommended to replace the pad module with a new one. For ordering the pad module, please consult your nearest dealer and follow the procedure in below to replace it.
  • Page 56 Assembling Procedure Take out the ADF pad module from the box. Use your fingers to hold the ADF pad module and place it gently to the pad holder as shown in Figure 2. ADF Pad Module Figure 2 Install the pad module...

  • Page 57: Troubleshooting

    TROUBLESHOOTING The scanner will automatically perform a simple self-test each time it is turned on. This will help spot major system errors in the scanner itself. When the test is initiated, the READY LED is flashing. When the test is completed, the READY LED is steadily on.
  • Page 58 Question: More than one sheet of paper were fed into the scanner. 1) Open ADF unit. Answer: 2) Remove the multi-fed sheets of paper. 3) Close the ADF unit. 4) Flatten the corners and edges; loosen the paper before reloading it in the paper guide. 5) Check the feeding roller condition and do the cleaning if necessary.
  • Page 59 Question: Getting an image from the scanner is not a problem, but, when scanning, the scanner or system will often crash. Please check Answer: 1) If the cable is firmly seated; 2) Please note only two SCSI terminators can be connected to your SCSI daisy chain.

  • Page 60: Paperjam In The Adf

    PAPERJAM IN THE ADF In case of paper jam, please follow the procedures below. Turn off the scanner. Press the button at the front left of the scanner The ADF cover will pop up a little. Backward on its hinge, open the ADF cover to its full position. Pull the paper gently out of the ADF unit.
  • Page 61 ADF Unit ADF Paper Chute Document Figure 6-2 Handle the paper jam problem - pull out the paper.

  • Page 62: Technical Service

    TECHNICAL SERVICE Technical support for Avision scanner is provided at Avision Technical Assistance Center (ATAC). Before contact with ATAC, please prepare the following information. Scanner serial & revision number (located on the bottom of the scanner) Hardware configuration (e.g., your host CPU type, RAM size, free disk space, display card, interface card, etc.)

  • Page 63: Specifications

    SPECIFICATIONS All specifications are subject to change without notice. Scanner Type 1-pass color Flatbed with ADF built-in Scanning Mode 36-bit color 12-bit Gray scale Line Art / Halftone Error Diffusion (single bit) Optical Resolution 300 * 600 dpi Light Source Cold cathode fluorescent lamp ADF Capacity 50 pages...
  • Page 64 The following can not be properly fed by the ADF: Paper with clip or staple attached; Paper with ink not totally dry; Paper with inconsistent thickness, such as envelopes; Paper with wrinkles, curls, folds or tears; Tracing paper; Coated paper; Carbonless paper;...
