3. Connecting the Adapter
System Configuration
Connect the adapter between the host machine and the user system so that the adapter can serve
as an emulator under control of the host machine. For using emulator debugger software on the
host machine, refer to the "S
Figure 3 shows the system configuration.
Host
machine
USB cable
Interface cable (adapter's flat cable)
Connection to the Host Machine
Connect the adapter to the host machine using the USB cable.
Figure 4 shows how to plug the USB cable.
Workbench OPERATION MANUAL".
OFTUNE
Adaptor
Figure 3 System Configuration
Connection to the USB
connector of the adapter
Figure 4 Plugging the USB Cable
Adapter
User
interface
interface
connector
connector
Adapter
MCU
User system
3
