Fujitsu UTY-TFNXZ1 Design & Technical Manual

Wireless lan adapter. optional part.
Hide thumbs

Advertisement

OPTIONAL PART
Wireless LAN adapter
DESIGN & TECHNICAL MANUAL
WIRELESS LAN
ADAPTER
UTY-TFNXZ1
UTY-TFNXZ2
UTY-TFNXZ3
UTY-TFNXZ4
DR_OP001EX_03
2018.04.26

Advertisement

loading

  Also See for Fujitsu UTY-TFNXZ1

  Related Manuals for Fujitsu UTY-TFNXZ1

  Summary of Contents for Fujitsu UTY-TFNXZ1

  • Page 1 OPTIONAL PART Wireless LAN adapter DESIGN & TECHNICAL MANUAL WIRELESS LAN ADAPTER UTY-TFNXZ1 UTY-TFNXZ2 UTY-TFNXZ3 UTY-TFNXZ4 DR_OP001EX_03 2018.04.26...
  • Page 2 • Product specifications and design are subject to change without notice for future improvement. • For further details, please check with our authorized dealer. Trademarks The following term and logo are trademarks of Fujitsu General Limited in the United States, other countries or both: ™...
  • Page 3: Table Of Contents

    CONTENTS WIRELESS LAN ADAPTER..............1 1. Applicable indoor units ................2 2. Model lineup ....................3 3. Overview ......................4 3-1. Wireless LAN control .......................5 4. Specifications....................7 4-1. Wireless LAN adapter ......................7 5. Wiring design ....................8 5-1. System diagram .......................8 6. Installation ....................10 6-1. Precautions ........................10 6-2.
  • Page 5: Wireless Lan Adapter

    WIRELESS LAN ADAPTER MODEL NAME: UTY-TFNXZ1 UTY-TFNXZ2 UTY-TFNXZ3 UTY-TFNXZ4...
  • Page 6: Applicable Indoor Units

    **: Alphanumeric characters are printed on the product. For details on applicable indoor units, refer to the product catalogue posted on “Support & Down- loads” page of the web site. http://www.fujitsu-general.com/global/support/ NOTE: Combined use of WLAN adapter and wired remote controller is prohibited. - 2 -...
  • Page 7: Model Lineup

    2. Model lineup Model name Region or country UTY-TFNXZ1 Europe UTY-TFNXZ2 North America, Middle East UTY-TFNXZ3 Oceania, Thailand, Vietnam, India UTY-TFNXZ4 China - 3 - 2. Model lineup...
  • Page 8: Overview

    3. Overview a LED 1 (green) Operation status indicator. b LED 2 (orange) Wireless LAN status indicator. c Setting button Used for connecting to wireless router. Schematic diagram: WLAN adapter Internet Indoor unit Wireless LAN router Smart device Smart device - 4 - 3.
  • Page 9: Wireless Lan Control

    After installation of mobile app, user registration is required. For user registration and setup infor- mation, refer to Setting Manual attached with the product. For the latest version of the Wireless LAN (WLAN) control manuals, refer to the following web site. https://www.fujitsu-general.com/global/support/ - 5 - 3-1. Wireless LAN control...
  • Page 10 ¢ Wireless LAN function list NOTE: To use Wireless LAN control, user registration in advance and access to the wireless home network are required. Item Mobile app Operation on/off ○ Operation mode setting ○ Set temperature setting ○ Fan speed setting ○...
  • Page 11: Specifications

    4. Specifications 4-1. Wireless LAN adapter Unit: mm (in) Top view 15 (9/16) 38 (1-1/2) Top view Side view Maximum radio-frequency power 71 × 38 × 15 2-15/16 × 1-1/2 × 9/16 Dimensions (H × W × D) 50 × 207 × 138.5 Gross 1-15/16 ×...
  • Page 12: Wiring Design

    5. Wiring design 5-1. System diagram One WLAN adapter can be connected to each indoor unit. Single system Multiple system Outdoor unit Outdoor unit Indoor unit Indoor unit Indoor unit WLAN adapter WLAN adapter WLAN adapter A, B, and C: Attached cable with this product. NOTE: Combined use with wired remote controller is prohibited.
  • Page 13 Prohibited uses: (1) Combined use with wired remote controller (2) Group connection of indoor units Indoor unit Indoor unit Indoor unit (3) Use in simultaneous multi system (4) Extended wiring Extending the cable is prohibited. Outdoor unit Indoor unit Indoor unit Indoor unit Junction box - 9 -...
  • Page 14: Installation

    6. Installation CAUTION To prevent personal injury, property damage, or product malfunction, read the setting manual at- tached with the product carefully, and be sure to comply with the safety precautions. 6-1. Precautions CAUTION • Do not bundle the WLAN adapter wiring with the connection cable running between the indoor and outdoor units, or the power supply cable.
  • Page 15: Installation Procedure

    6-2. Installation procedure WARNING • Disconnect the power supply or turn off the breaker before starting work. Failure to disconnect the power supply may lead to electric shock or fire. • Do not turn on the power until all installation work is complete. •...
  • Page 16: Initial Setup

    7. Initial setup By using FGLair, perform initial setup for WLAN control. NOTE: Make sure that the smart device is connected to the same wireless router that the WLAN adapter is connected. 7-1. Mobile app installation and user registration Visit Google Play store or App Store according to the type of connecting smart device. Search for FGLair in the store.
  • Page 17: Accessories

    Q’ty Part name Exterior Q’ty Tapping screw Setting manual M4 × 25 mm Operating manual Wireless LAN label MAC:____________ SSID: AC-UTY-____________ PIN: ________ (CD-ROM)* Important : Please do not discard. *: Available only for UTY-TFNXZ1. - 13 - 8. Accessories...
