Tripp Lite B006-VUA4-K-R Quick Manual

Model Number: B006-VUA4-K-R
KVM Switch - 4-Port KVM Switch with Audio, OSD and Peripheral Sharing
Description
Tripp Lite's B006-VUA4-K-R is the optimal solution for controlling multiple computers, audio and USB peripherals, and can be used in either a
desktop environment or mounted in a 19in rack. Connect up to 4 USB computers with the included 4 USB KVM cable kits, or use P757-010 PS/2
KVM cable kits to connect PS/2 computers. Built-in 3.5mm jacks allow for speaker and microphone audio to be shared amongst the connected
computers. Also built-in is a 2-Port USB 2.0 hub, which allows for the sharing of USB devices amongst computers connected via USB KVM cable
kits. KVM console, Audio and USB can be switched independently of each other - Control one computer while listening to audio from a second
computer and printing to a USB printer from a third. Switch the focus of KVM, Audio and USB functionality using pushbuttons, OSD, hotkey
commands, auto scan mode or the mouse switching function. The mouse switching function allows focus to be switched between ports by
double-clicking the scroll button on a scroll mouse. The on-screen display (OSD) provides two levels of security, with 1 Administrator account and up
to 4 User accounts, and can be displayed in English, Japanese or German. It supports video resolutions up to 2048 x 1536, and features a compact
design that does not require software or complicated set-up procedures. Compatible with Windows, Mac, Linux, Sun, UNIX, Novell and DOS.
Applications
Small Office/Home Office (SOHO). Control multiple computers, audio and USB peripherals, and use in either a desktop environment or
mount in a 19in rack.

Package Includes

B006-VUA4-K-R KVM switch
(4) USB + Audio KVM cable kits
PS/2 to USB adapter cable
Firmware upgrade cable
19in rackmount hardware
External Power Supply (Input: 100-240V, 0.5A, 50/60Hz Output: 5.3V, 2.4A)
Owner's Manual
Features
Control up to 4 computers from a single monitor, keyboard and mouse
Package includes (x2) 4 ft. and (x2) 6 ft. USB + Audio KVM cable kits
P756-010 10 ft. USB + Audio KVM cable kits are available separately if longer lengths are required
Highlights
Control up to 4 USB or PS/2 computers from a single monitor, keyboard and
mouse
Package includes 4 USB + Audio KVM cable kits
Includes a built-in 2-Port USB 2.0 hub for sharing of devices amongst
computers connected with a USB KVM cable kit
Built-in 3.5mm audio jacks allow speaker and microphone audio to be shared
amongst the connected computers
2-Level security - 1 Administrator and up to 4 Users
Compatible with all major operating systems
