- Page 1 FB-03/04...
-
Page 2: Table Of Contents
User Manual Contents Product Overview Disassemble Chart Accessory Box Installation Guide Opening Chassis Installing 2.5” HDD/SSD Installing Power Supply Installing Motherboard Installing Add-On Card Installing External 5.25"/3.5” Device Installing 3.5” HDD Closing Chassis Information © All rights reserved by Rosewill... -
Page 3: Disassemble Chart
PORT1L PRESENCE# PORT1R AUD GND MIC~BIAA SENSE1 RETURN PORT2R RET~R FPOUT~R NO PIN SENSE SEND NO PIN SENSE2 RETURN PORT2L RET~L FPOUT~L NO PIN NO PIN USB2.0 CONNECTOR USB+5V USB+5V NO PIN NO PIN © All rights reserved by Rosewill... -
Page 4: Accessory Box
29 x screw-A 5.25”/3.5” Device 2.5” SSD/HDD 16 x screw-B 3.5” HDD Power Supply 11 x screw-C Add-on Card 1 x PC SPEAKER Motherboard 5 x Cable tie Cables 2 x PCI cover Expansion Slot © All rights reserved by Rosewill... -
Page 5: Opening Chassis
CASE FB-03/04 User Manual 1. Opening Chassis Unscrew to remove left and right panels. 2. Installing 2.5” HDD/SSD Place 2.5” HDD/SSD onto the bottom of the chassis and secure with screws. * screw-A © All rights reserved by Rosewill... -
Page 6: Installing Power Supply
Step 2- Place the motherboard onto stand-offs Step 1- Install motherboard stand-offs according and secure with screws. to your motherboard’s form factor. NOTE : NOT every motherboard is made by standard, please set stand-offs according to your motherboard. © All rights reserved by Rosewill... -
Page 7: Installing Add-On Card
Step 1- Unscrew add-on card cover. Step 2- Release add-on card cover. Step 3- Remove PCI slot cover. Step 4- Install add-on card and secure with screw. Step 5- Close add-on card cover and secure with screw. © All rights reserved by Rosewill... -
Page 8: Installing External 5.25"/3.5" Device
-Confirm which bay(s) you want to install device(s) then remove the bay cover. 7. Installing External 5.25"/3.5” Device * screw-A Insert the external 5.25” & 3.5” device from the front panel into the chassis then secure with screws. © All rights reserved by Rosewill... -
Page 9: Installing 3.5" Hdd
CASE FB-03/04 User Manual 8.Installing 3.5” HDD * Screw-B Place the 3.5” HDD into the HDD tray then secure with screws. © All rights reserved by Rosewill... -
Page 10: Closing Chassis
Please register your product at : http://www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for latest driver & user manual or feel free to contact us.
