Product Overview Product Diagram (Components vary by country) Right Side Panel Back 80mm Fan Front 120mm Fan Left Side Panel Front Panel Front I/O Pin-out USB 3.0 CONNECTOR USB 2.0 CONNECTOR HD AUDIO CONNECTOR...
Page 5
Front I/O Diagram Accessory Kit Image Part Name Function/Component M / B Standoff Motherboard ( Pre-installed ) Screw-A Power Supply Screw-B Motherboard / 3.5" HDD PC Speaker Motherboard Cable Tie Cable Management...
Page 12
Model Model Name FBM-X1 Features Type Mini Tower Color Black Case Material Steel/Plastic Power Supply Mounted Motherboard Compatibility Micro ATX, Mini ITX Side Panel Window Expansion External 5.25" Drive Bays Internal 3.5" Drive Bays Internal 2.5" Drive Bays Expansion Slots Front Ports USB 3.0 x 2...
