[Image process] The image processing includes:
Brightness
Contrast
Saturation
Use the mouse to drag the slider to configure these settings as shown in
figure 3-2. The "Reset" button on the camera can be used to recover the
default configuration.
[Color and Direction Configuration] The image color can be set to either black
and white or color. The image orientation can be mirrored or reversed as seen in
Figure 3-3. NSTC or PAL also can be set in this section.
[PTZ control] PTZ control allows the following camera motions: upward, downward,
left, and right. The lens operation includes vary magnification, vary focus, vary iris,
etc. This control is shown in Figure 3-4.
Figure 3-2
Figure 3-3
Figure 3-4
Image parameter adjustment
Color and direction control
PTZ control
[System Parameter Settings] Click this button
to enter into the System
Settings interface. From here, you can configure many of the settings within the
camera.
[Reboot Device] Click this button
to reboot the device.
10
