Exélia Art Custom Products
User Guide
0459

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Exelia Art and is the answer not in the manual?

Questions and answers

Related Manuals for Phonak Exelia Art

Summary of Contents for Phonak Exelia Art

  • Page 1 Exélia Art Custom Products User Guide 0459...

  • Page 2: Table Of Contents

    Contents Welcome Description Preparation Replacing the battery Identifying left and right hearing systems Inserting your hearing system in your ear Removing your hearing system from your ear Fine tuning your hearing system Operation Switching ON/OFF Controlling the volume (optional) Hearing programs Synchronized manual control ZoomControl Telecoil (optional)
  • Page 3 Wireless accessories (optional) myPilot iCom iView Remote control (optional) FM communication (optional) MyLink Dynamic FM transmitters Maintenance Important points SmartGuard (optional) Warning Service and Warranty Phonak distributors worldwide...

  • Page 5: Welcome

    Exélia Art is a quality product developed by the Swiss company Phonak, a world leader in hearing technology, innovation and reliability. With proper care and usage, your hearing system will support your hearing and communication needs for many years.

  • Page 6: Description

    Description Exélia Art CIC/MC Petite Exélia Art CIC/MC P Petite Battery size 10 Exélia Art ITC/HS Petite Exélia Art ITC/HS P Petite Exélia Art ITC/HS Exélia Art ITC/HS P Battery size 312 Battery size 312...
  • Page 7 Exélia Art FS Exélia Art FS P Battery size 13 Protected microphone inlet (two on models with directional technology) Battery compartment with ON/OFF switch Program switch (optional) Volume control (optional) Receiver (sound outlet) and wax protection system Custom made shell Removal handle (Exélia Art CIC/MC) Vent...

  • Page 8: Preparation

    Preparation Replacing the battery Use a battery (size 10, 312, 13) for all Exélia Art Custom Products. Hold the hearing system with the battery compartment upwards and open it. Do not try to open the compartment further than shown in the drawing.
  • Page 9 Remove the old battery. Remove the protective foil from the new battery. Please wait 2 minutes before you insert the battery. Insert the new battery. Please ensure that the “+” sign on the battery (flat side) is on the same side as the “+” sign on the battery compartment.
  • Page 10 Preparation Gently shut the battery compartment, until you feel it “click” into place. Handle the battery compartment gently and do not use excessive force.
  • Page 11 If there is any resistance when closing the compartment, ensure that the battery is correctly inserted. The compartment will not close if the battery is inserted upside down. When your hearing system is not in use, leave the battery compartments open to allow any moisture to evaporate.

  • Page 12: Identifying Left And Right Hearing Systems

    Preparation Identifying left and right hearing instruments Before insertion, please ensure that you are using the proper left and right hearing systems. Your hearing systems are identified as follows: blue = left red = right...

  • Page 13: Inserting Your Hearing System In Your Ear

    Inserting your hearing system in your ear Grasp the hearing system between the thumb and index finger, using the hand on the same side you wear your hearing system. Insert the canal end into the ear canal. Tug gently on your ear lobe and push the hearing system into the correct position.

  • Page 14: Removing Your Hearing System From Your Ear

    Preparation Removing your hearing system from your ear If possible, select the mute mode (see page 18) before removing your hearing system to avoid whistling. ½ Exélia Art CIC/MC (P) Petite with removal handle Grasp the handle between your thumb and index finger and pull the hearing system upwards out of your ear.
  • Page 15 ½ Exélia Art models without a removal handle Put your thumb behind your lobe (just below the hard cartilage) and gently press your ear upward to push the hearing system out of the canal. In order to help it along, make chewing movements with your jaw.

  • Page 16: Fine Tuning Your Hearing System

    Preparation Fine tuning based on your personal preferences The fitting process has limited capabilities of reproducing the full spectrum of your personal sound environments. This limitation is overcome by the ability of your hearing systems to learn from your real life volume adjustments.

  • Page 17: Operation

    Operation Switching ON/OFF Switching ON The hearing system is switched ON when the battery compartment is closed. Your hearing systems are automatically set at your preferred volume and in your default hearing program. Switching OFF To switch the hearing system OFF, open the battery compartment.
  • Page 18 Operation Operation Delayed activation The Exélia Art hearing system requires several seconds to start up. Your hearing care professional may have activated a further delayed activation timer. This function delays the activation of the hearing system (for 9 or 15 seconds) after the battery door is closed in order to avoid any disturbance while placing it on your ear.

  • Page 19: Controlling The Volume (Optional)

    Controlling the volume via optional volume wheel left ear right ear forwards forwards backwards backwards Preset volume Automatically set when hearing system is switched ON. To increase volume Turn the volume control forwards. To reduce volume Turn the volume control backwards.

  • Page 20: Hearing Programs

    Operation Note ½ A single beep indicates the preset volume setting. A double beep indicates that you have reached the limit of your volume control range. ½ The myPilot command center (see page 26) can also control the volume of all Exélia Art models (except Petite models), including the models without manual volume control.

  • Page 21: Synchronized Manual Control

    Additional program selection Upon request, your hearing care professional can program for you additional individual hearing programs dedicated to specific hearing situations. Additional programs are available via the myPilot command center, remote controls such as the KeyPilot2 or WatchPilot2 or with the optional program switch.

  • Page 22: Zoomcontrol

    Operation ZoomControl (for Exélia Art models with two microphones) This special hearing program allows you to choose from four directions in which to focus your hearing systems (front, back, left or right). This special program can be accessed via the myPilot command center or the program switch.

  • Page 23: Easyphone (Optional)

    EasyPhone (optional) The EasyPhone function enables your hearing system to automatically select your telephone program when the telephone handset is held close to your ear. An acoustic signal confirms the switch. It automatically returns to the previous hearing program when the telephone handset is removed from your ear.
  • Page 24 Operation If you hold the telephone receiver in your right hand when making telephone calls, position the magnet in the upper right half of the receiver. If you hold the telephone receiver in your left hand when making telephone calls, position the magnet in the upper left half of the receiver.

  • Page 25: Use Of Easyphone

    Use of EasyPhone Use the telephone in a normal manner. An acoustic signal indicates the activation of the EasyPhone program. At the beginning, you may need to move the handset slightly to find the optimum position for a reliable switch and comfortable hearing. If necessary, move the magnet to another position on the handset to increase your comfort of use.

  • Page 26: Wireless Accessories (Optional)

    Wireless accessories (optional) myPilot (not available for Exélia Art Petite instruments) The myPilot command center is an optional accessory for your instruments. It allows a convenient, user-friendly and discrete control of all the functions of your hearing system and additional benefits. ½...
  • Page 27 For optimum results, position your myPilot as shown in the drawing. Operating range max. 50 cm (20”) Do not use your myPilot in locations where it is forbidden to use electronic devices.

  • Page 28: Icom

    Wireless accessories (optional) iCom (not available for Exélia Art Petite instruments) iCom is an optional accessory available for your instruments. With the push of a single button, iCom connects your hearing system with the technology around you (mobile phones, audio equipment, FM, etc.). Bluetooth connections iCom offers a simple way to connect your mobile phone via Bluetooth to your hearing system.
  • Page 29 FM compatibility (not available for Exélia Art Petite instruments) iCom also offers FM accessibility when a Phonak FM receiver is connected, refer to picture below. EasyAudio and EasyBluetooth Your hearing systems contain two special audio programs: EasyAudio and EasyBluetooth. These programs are automatically selected in your hearing systems when an audio or Bluetooth signal is received from iCom.

  • Page 30: Iview

    Wireless accessories (optional) iView (not available for Exélia Art Petite instruments) iView, the status viewer, is an optional accessory for parents with small children and also for teachers or caregivers. Just by the press of a button, iView shows the status of the hearing instruments' batteries, the current hearing program and colume settings, displayed on a large screen.

  • Page 31: Remote Control (Optional)

    Remote control (optional) Phonak offers a comprehensive range of modern remote controls. Ask your hearing care professional to demonstrate them to you. Choose the model that is most convenient for your lifestyle and your taste. WatchPilot2 Exclusive and modern, available for women and...
  • Page 32 Remote control (optional) For best results with your KeyPilot2 or WatchPilot2 remote control, refer to the drawing. For detailed information on the use of your remote control, please refer to its user guide. Your hearing care professional can also print an individual description of your hearing programs for you.

  • Page 33: Fm Communication (Optional)

    FM communication is an option available for custom hearing instruments that are equipped with a Telecoil or with an iCom and a Phonak FM receiver. When noise, distance or reverberation is a problem, FM systems greatly improve communication. A wireless FM communication system consists of a transmitter and a receiver.

  • Page 34: Dynamic Fm Transmitters

    FM communication (optional) Dynamic FM transmitters Phonak offers Dynamic FM transmitters for all customers and needs: inspiro The transmitter for teachers and suitable for use in schools SmartLink+ For teenagers and adults who want nothing less than the very best...

  • Page 35: Maintenance

    Avoid strong jolts and vibration. 5) Daily cleaning and the use of a drying system is highly recommended. "C&C line" from Phonak is a complete set of cleaning products. Your hearing care professional will be glad to advise you. Never use household cleaning products (washing powder, soap, etc.) to clean your hearing systems.
  • Page 36 Maintenance 6) Hair spray, face creams and make-up can damage hearing systems. Remove them before applying cosmetics. 7) If you experience any soreness or inflammation in your ear, contact your hearing care professional. 8) If your hearing system is performing weakly or fails to operate, clean or replace the wax guard system.

  • Page 37: Smartguard (Optional)

    SmartGuard (optional) SmartGuard is a unique wax protection system developed by Phonak. The unique membrane design completely protects your hearing system from wax and moisture. Please ask your hearing care professional for further information.

  • Page 38: Warning

    Hearing systems in directional microphone mode reduce mainly background sounds. Warning signals coming from behind and vehicles’ horns approaching from behind are partially or completely suppressed. Changes or modifications made to this equipment not expressly approved by Phonak are not allowed.

  • Page 39: Service And Warranty

    Damage caused by third parties or non-authorized service centers renders the Phonak warranty null and void. This warranty does not include any services performed by hearing care professionals in their offices. This warranty applies to the Phonak products listed below: Serial number –...
  • Page 40 2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made to this equipment not expressly approved by Phonak may void the FCC authorization to operate this equipment. Notice 2 This Class B digital apparatus complies with Canadian...
  • Page 41 Notice 3 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 42: Phonak Distributors Worldwide

    France Phonak France SA, 69500 Bron Germany Phonak GmbH, 70736 Fellbach- Oeffingen, EC Representative India Phonak India Pvt. Ltd., 100 034 New Delhi Italy Phonak Italia S.r.l., 20159 Milano Japan Phonak Japan Co., Ltd., Tokyo 101-0044 Jordan Phonak Middle East, 11181 Amman Mexico Phonak Mexicana, S.A.
  • Page 43 Poland Phonak Polska SP Z.0.0 00-567 Warszawa Portugal Phonak Ibérica S.A., 03008 Alicante, Spain Russian Federation Phonak CIS Ltd., Moscow, 115114 Spain Phonak Ibérica S.A., 03008 Alicante Sweden Phonak AB, 117 43 Stockholm Switzerland Phonak AG, Phonak Schweiz, 8712 Stäfa Turkey Phonak Turkey A.S., 34357 Istanbul...
  • Page 44 The CE symbol is a confirmation by Phonak AG that Exélia Art products and accessories XXXX meet the requirements of directive 93/42/EEC on medical devices and the R&TTE Directive 1999/5/EC on Radio and Telecommunication Terminal Equipment. The numbers after the CE symbol are the numbers of consulted certified bodies under the above mentioned directives.
  • Page 45 Transportation and Temperature should not exceed limits of storage conditions –20°/60° Celsius at a relative air humidity of 65% for extended periods during transportation and storage. Air pressure between 500 and 1100 hPa is not detrimental to the instrument. Australia & New Zealand Brazil China Japan...
  • Page 46 Notes...
  • Page 48 www.phonak.com...
