American Standard ACRYLUX 6032Y1.102 Features & Dimensions

ACRYLUX 60" x 32" w/INTEGRAL APRON
❑
6032Y1.102 Bathing Pool, Right Drain
❑
6032Y1.202 Bathing Pool, Left Drain

Product Features:

• High-gloss acrylic-capped ABS with
fiberglass reinforcement
• Integral apron
• Integral three-sided, tiling/water retention flange
• Integral lumbar support
• Pre-leveled tub bottom
❑ 6032Y1.118 Whirlpool, Right Drain
❑
6032Y1.218 Whirlpool, Left Drain

Whirlpool Features:

• 1.25 hp, single-speed pump motor
• 8 whirlpool jets
– 4 adjustable jets
– 4 mini-jets in the lumbar and foot areas
• Deck mounted air on/off switch
• Removable access panel

Nominal Dimensions:

59-7/8" x 32" x 18"
(1521 x 813 x 457mm)
For use with:
• 6032Y1.BW Bath Wall Set
• 6032Y1.BWT Bath Tile Wall Set
• Tub can also be installed without
Acrylux wall set

Compliance Certifications -

Meets or Exceeds the Following Specifications:
• UL 1795 for Hydromassage Bathtubs
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
© 2008 AS America Inc.
ACRYLUX 60" x 32" w/INTEGRAL APRON
™
WHIRLPOOL AND BATHING POOL
H129
HIGH GLOSS
6032Y1.102
6032Y1.118
Revised 5/08
