American Standard ACRYLUX 6030Y1.102 Features & Dimensions

ACRYLUX 60" x 30" BATH w/INTEGRAL APRON
❑ 6030Y1.102 Bathing Pool, Right Drain
❑ 6030Y1.202 Bathing Pool, Left Drain

Product Features:

• High-gloss acrylic-capped ABS with
fiberglass reinforcement
• Integral apron
• Integral three-sided, tiling/water
retention flange
• Integral lumbar support
• Pre-leveled tub bottom
❑
6030Y1.118 Whirlpool, Right Drain
❑ 6030Y1.218 Whirlpool, Left Drain

Whirlpool Features:

• 1.25 hp, single-speed pump motor
• 6 whirlpool jets
– 4 adjustable jets
– 2 mini-jets in the lumbar area
• Deck mounted air on/off switch
• Removable access panel

Nominal Dimensions:

59-7/8" x 30" x 15"
(1521 x 762 x 381mm)
For use with:
• 6030Y1.BW Bath Wall Set
• 6030Y1.BWT Bath Tile Wall Set
• Tub can also be installed without Acrylux
wall set

Compliance Certifications -

Meets or Exceeds the Following specifications:
• UL 1795 for Hydromassage Bathtubs
• ASME A112.19.7M for Whirlpool Appliances
• ANSI Z124.1 for Plastic Bathtubs
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density
© 2008 AS America Inc.
ACRYLUX 60" x 30" w/INTEGRAL APRON
™
WHIRLPOOL AND BATHING POOL
H123
HIGH GLOss
6030Y1.102
6030Y1.218
Revised 5/08
