ACRYLUX 60" x 30" BATH w/INTEGRAL APRON
❑
6030Y1.102 Bathing Pool, Right Drain
❑
6030Y1.202 Bathing Pool, Left Drain
Product Features:
• High-gloss acrylic-capped ABS with
fiberglass reinforcement
• Integral apron
• Integral three-sided, tiling/water
retention flange
• Integral lumbar support
• Pre-leveled tub bottom
❑
6030Y1.118 Whirlpool, Right Drain
❑
6030Y1.218 Whirlpool, Left Drain
Whirlpool Features:
• .25 hp, single-speed pump motor
• 6 whirlpool jets
– 4 adjustable jets
– 2 mini-jets in the lumbar area
• Deck mounted air on/off switch
• Removable access panel
Nominal Dimensions:
59-7/8" x 30" x 5"
(52 x 762 x 38mm)
For use with:
• 6030Y.BW Bath Wall Set
• 6030Y.BWT Bath Tile Wall Set
• Tub can also be installed without Acrylux
wall set
Compliance Certifications -
Meets or Exceeds the Following specifications:
• UL 795 for Hydromassage Bathtubs
• ASME A2.9.7M for Whirlpool Appliances
• ANSI Z24. for Plastic Bathtubs
© 2008 AS America Inc.
ACRYLUX
60" x 30" w/INTEGRAL APRON
™
WHIRLPOOL AND BATHING POOL
HIGH GLOss
6030Y.02
6030Y.28
Revised 5/08
