  • Page 1 User Manual...

  • Page 2: Table Of Contents

    ABLE OF ONTENTS 1. Before You Begin................3 What Is Included ................... 3 Unpacking Instructions .................. 3 Claims ........................3 Text Conventions ..................3 Icons ......................3 Disclaimer ..................... 3 Product at a Glance ..................4 Safety Notes ....................4 2. Introduction..................5 Product Overview ..................

  • Page 3: Before You Begin

    CHAUVET®. Failure to do so in a timely manner may invalidate your claim with the carrier. In addition, keep the container and all the packing material for inspection.

  • Page 4: Product At A Glance

    Product at a Use on Dimmer Auto Programs   Glance Outdoor Use Auto-ranging Power Supply   Sound Activated Replaceable Fuse   User Serviceable   Master/Slave Duty Cycle   Safety Notes Please read the following Safety Notes carefully before working with the product. The Notes include important safety information about installation, usage, and maintenance.

  • Page 5: Introduction

    2. I NTRODUCTION Product Overview Touch Display Power In Power Out DMX In Mounting Bracket DMX Out SlimPANEL™ TRI 12 IP User Manual (Rev. 3) Page 5 of 16...

  • Page 6: Product Dimensions

    Product Dimensions Page 6 of 16 SlimPANEL™ TRI 12 IP User Manual (Rev. 3)

  • Page 7: Setup

    The power linking information above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region.

  • Page 8: Mounting

    Mounting Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The SlimPANEL™ TRI 12 IP may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes.

  • Page 9: Operation

    4. O PERATION Control Panel To access the control panel functions, use the four buttons located underneath the display. Please refer to the Product Overview to see the button locations on the control Operation panel. Button Function Press to find an operation mode or to back out of the current menu <MENU>...

  • Page 10: Configuration (Dmx)

    Configuration Set the product in DMX mode to control with a DMX controller. Connect the product to a suitable power outlet. (DMX) Turn the product on. Connect a DMX cable from the DMX output of the DMX controller to the DMX input socket on the product.

  • Page 11: Dmx Channel Assignments And Values

    DMX Channel Assignments and Values 3-CH Channel Function Value Setting 000  255 0~100% Green 000  255 0~100% Blue 000  255 0~100% 4-CH Channel Function Value Setting Dimmer 000  255 0~100% 000  255 0~100% Green 000  255 0~100% Blue 000 ...

  • Page 12: Configuration (Standalone)

    Configuration Set the product in one of the standalone modes to control without a DMX controller. Connect the product to a suitable power outlet. (Standalone) Turn the product on. Never connect a product that is operating in any standalone mode (Static, Automatic, or Sound) to a DMX string connected to a DMX controller.

  • Page 13: Touch Control Panel Lock

    Touch Control To enable the touch panel lock, follow the instructions below: Panel Lock Press <MENU> repeatedly until PASS shows on the display. Press <ENTER>. Press <UP> or <DOWN> until ON shows on the display to enable the touch panel lock.

  • Page 14: Technical Information

    5. T ECHNICAL NFORMATION Product Dust build up reduces light output performance and can cause overheating. This can lead to reduction of the light source’s life and mechanical wear. To maintain optimum Maintenance performance and minimize wear, you should clean your lighting products at least twice a month.

  • Page 15: Technical Specifications

    6. T ECHNICAL PECIFICATIONS Dimensions and Length Width Height Weight Weight 14 in (358 mm) 7 in (180 mm) 3.5 in (90 mm) 10.5 lbs (4.8 kg) Note: Dimensions in inches rounded to the nearest decimal digit. Power Power Supply Type Range Voltage Selection Switching (internal)

  • Page 16: Returns

    If you live in the U.S., contact CHAUVET® World Headquarters (see below). • If you live in the UK or Ireland, contact CHAUVET® Europe Ltd. (see below). • If you live in any other country, DO NOT contact CHAUVET®. Instead, contact your distributor of record.
