Summary of Contents for Chauvet Line Dancer LED
-
Page 1: User Manual
Snapshot Use on Dimmer Outdoor Use Sound Activated Master/Slave Auto-ranging Power Supply Replaceable Fuse User Serviceable Duty Cycle User Manual 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
PECIFICATIONS ...................................... 12 ONTACT CHAUVET® Lighting. 2012. All Rights Reserved. Information and specifications in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual. -
Page 3: What Is Included
Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
• Built-in sound activated programs via master/slave or DMX Ad d i t i o n a l F e a t u r e s • Additional power output: max 30 units Line Dancer LED User Manual Rev. 2... -
Page 5: Product Overview
Hanging/Standing Brackets (2) Bracket Adjustment Knobs(2) Product Overview (rear panel) Power Indicator Safety Attachment Point DIP Switches DMX Out Signal Indicator DMX In Sound Sensitivity Power Adjustment Knob In/Fuseholder Microphone Power Link Out Line Dancer LED User Manual Rev. 2... -
Page 6: Setup
This product contains power linking via the edison outlet located in front of the power input cable. Please see the diagram below for further explanation. The maximum quantity of products that may be linked is 30. Fixture #1 Fixture #2 Fixture #3 Additional power link out Line Dancer LED User Manual Rev. 2... -
Page 7: Orientation
Mounting Orientation The Line Dancer LED™ may be mounted in any safe position, provided there is adequate room for ventilation. Rigging Be sure that the structure can support the weight of the product. Please see the “Technical Specifications” section of this manual for a detailed weight listing. Mount the product securely. This may be done with a screw, nut and bolt, or a hanging clamp. -
Page 8: Operating Instructions
102, 103, 104, 105 and 106. Choose the starting addresses for each product so that the channels used do not overlap. In addition, you should note the starting address selected for future reference. The Line Dancer LED™ product uses four DMX channels. If this is your first time using DMX, download the DMX Primer from www.chauvetlighting.com. -
Page 9: Standalone Operation
Slow ~ Fast Run Speed (only when CH.1 is between 161~240) 000 009 No Function 010 255 Slow ~ Fast Motor Speed 000 009 No Function 010 255 Slow ~ Fast Line Dancer LED User Manual Rev. 2... -
Page 10: Appendix
Never spin a fan using compressed air. Data Cabling To link products together you must obtain data cables. You can purchase CHAUVET® certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 11: General Troubleshooting
Package must be clearly labeled with a Return Merchandize Authorization Number (RMA #). Products returned without the RMA # will be refused. Call CHAUVET® and request an RMA # prior to shipping the product. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Technical Specifications
PHOTO OPTIC Coverage Angle ................................70° THERMAL Maximum ambient temperature ........................104° F (40° C) ORDERING INFORMATION Line Dancer LED™ ..........................LINCEDANCERLED WARRANTY INFORMATION Warranty ............................2-year limited warranty Contact Us W o r l d W i d e General Information CHAUVET®...
