- Page 1 WASHING MACHINE INSTRUCTIONS MANUAL EWT 1058...
-
Page 3: For The User
For the user Warnings Keep this instruction book with the appliance. If the appliance is sold or transferred to another owner, ensure that the book is supplied with the appliance. The new user can then find out about the operation of the appliance and the relevant warnings. - Page 4 Disposal Packaging Appliance When disposing of your old appliance, make it unusable • All materials marked with the symbol are recy- as it may represent a danger: cut the electric cable and clable. Dispose of them in a tip designed for this purpose make the door catch unusable.
-
Page 5: Table Of Contents
Contents For the user Maintenance and cleaning Descaling the appliance After each wash cycle Warnings External cleaning Detergent dispenser Drain filter Description of the appliance Troubleshooting Control panel Description of controls 7-10 After-Sales Service Using the machine 11-12 Loading the laundry Measuring the detergent Additives For the installation engineer... -
Page 6: Description Of The Appliance
Description of the appliance Display window Programme progress Start / Pause button Options Programme selector Lid handle Lever for placing appliance on rollers Filter access flap Detergent dispenser Symbols 1 - prewash ( 2 - wash ( ) (powder or liquid detergent) 3 - softener ( ) 4 - softener overflow... -
Page 7: Control Panel
Control panel 1. Programme selector Options buttons It is used to select the most suitable programme to the The various options should be chosen after the type and soiling of your laundry as well as the tempe- programme has been displayed and before pressing rature of the washing. -
Page 8: Extra Rinse Button
No spin Modifying the delay start If you select the " " position, the appliance drains the water only. This function cannot be selected with the • Press the Start/Pause button. Whites and Coloureds programmes. This function is • Press the Delay start button until the new number of very useful for very delicate laundry. -
Page 9: Start/Pause Button
Pause The programme in progress is interrupted when this button is pressed. It continues when this button is pressed again. During the pause, the light of the Start/ Pause button flashes. Drain By pressing the Start/Pause button: • The water from the soak programme is drained. Incorrect selection •... - Page 10 Information about the programme Wool Spin With this programme, woollen garments which contain This programme spins the washing at maximum speed. the words “pure new wool, machine washable, does not A different spin speed can be selected depending on shrink” on the care label can be washed but also wool- the nature of the washing using the Spin button.
-
Page 11: Using The Machine
Using the machine 4. Selecting the desired programme Before using your appliance for the first time, we recommend you to perform a preliminary wash, without laundry, to clean the drum and tub if necessary: - Pour an amount of detergent into the “wash” compart- ment. -
Page 12: Selecting The Desired Option
8. Selecting delay start - Opening the lid at the end of the cycle: The immediate opening of the lid is signalled by a double Before starting the programme, if you want to delay it, “click” of the locking device. The immediate opening press this button until the desired delay start is dis- light "Door"... -
Page 13: Washing Guide
Removing stains Washing guide Remove certain stains which may not come out, espe- cially if they are old, by working from the outside of the Sorting the laundry into categories: stain towards the inside to avoid making rings. To obtain the best washing results, we recommend that Grass. -
Page 14: Maximum Laundry Loads Depending On Fabric Type
Note : Only use low foaming detergents, specially Maximum laundry loads depend- designed for use in wahing machines. Use neutral ing on fabric type products for washing wool. The amount of laundry placed in the drum must not If you use liquid detergents, place the dosing ball exceed the maximum capacity of the appliance. -
Page 15: International Wash Care Symbols
International wash care symbols NORMAL WASH Washing Washing Washing Washing Delicat Do not 95°C 60°C 40°C 30°C hand wash washing DELICATE WASH Do not use chorine black BLEACHING Chlorine bleach may be used (cold wash only and with a diluted solution.) High temperature Medium temperature... -
Page 16: Programme Chart
Programme chart WASH PROGRAMMES Position of Wash programme Possible Max. Indicative consumptions (*) programme options load Water Power Time selector liters min. Whites Whites, e.g. normally Prewash 5,0 kg 2,00 soiled work clothes, Quick bed linen, table linen, Water in the tub clothes, towels Extra rinse Energy saving... - Page 17 Programmes chart SPECIAL PROGRAMMES Position of the Programme Wash programme Possible Max. Indicative consumptions (*) programme description options load Water Power Time selector liters min. For very dirty Presoak at 30°C. 5,0 kg 0,30 Soak laundry except Rinse hold. wool To drain, press Start/pause button.
-
Page 18: Maintenance And Cleaning
Maintenance and cleaning Disconnect the appliance before cleaning. Refitting : Descaling the appliance Reposition the detergent dispenser in the slots until it is It is not generally necessary to descale the appliance if clipped in. the correct amount of detergent is used. However, if scale builds up, use a specific non corrosive product specially designed for washing machines avail- able in the shops. -
Page 19: Troubleshooting
Troubleshooting The manufacturing process of your appliance has been subject to many checks. However, if you notice an operating fault, refer to the table below before calling the after-sales service. Whilst the appliance is operating, the following error codes may appear in the display window (and the cycle progress lights may flash, see page 12). E10 + "Rinse"... - Page 20 Solutions Symptoms Check that: The machine vibrates or is very the transit bolts have been removed (see "removing noisy. transit bolts" section), the appliance is level and installed correctly, the appliance is not too close to a wall or other furniture, the laundry is correctly distributed in the drum, the appliance is not overloaded.
-
Page 21: After-Sales Service
After-Sales Service If an operating fault occurs, refer to the “TROU- BLESHOOTING” section. If, despite all the checks, a repair is deemed necessary, contact the retailer of your appliance in the first instance. Failing this (if you have moved house, if the shop where you bought the appliance has closed, etc), please contact the Consumer Technical Assistance which will then inform you of the address of an After-... -
Page 22: For The Installation Engineer
For the installation engineer Warnings Installation • This appliance is heavy. Take care when moving it. • Before connecting your appliance, carefully read the instructions given in the "Electrical connection" sec • The transit bolts must be removed before use. Failure tion. -
Page 23: Installation
Installation Removing the transit bolts Parts used to protect the internal components of the appliance during transport must be removed before the appliance is used for the first time. These parts and their mountings must be kept for future transport. 1. -
Page 24: Levelling
Levelling Draining The end of the drain hose can be placed in two different ways: In a drain pipe (or branch of the sink drain pipe), of which the distance from the floor must be between 70 and 100 cm. Level the appliance by raising or lowering the feet. -
Page 25: Electrical Connection
Electrical connection This appliance can only be connected to 230 V single phase. Ensure that the household meter and fuses can with- stand the current absorbed by the appliance, taking into account the other electrical appliances connected. Rating of the line fuses (one per phase): 10 A for 230 V. - Page 26 02/02...
