Daewoo FR-171 Instruction Manual

MAME OF PARTS
! FREEZER SHELF
@ ICE BOX
# ICE TRAY
$ TEMP CONTROL DIAL
% LAMP SWITCH
^ SHELF
& CRISPER COVER B
* VEGETABLE
CRISPER
( FREEZER POCKET
) EGG POCKET
1 BOTTLE POCKET(S)
2 BOTTLE POCKET(L)
3 ADJUST FOOT
1
Here are the features of your new refrigerator.
Take a moment to know all the features and convenience it was designed to
provide. Numbers match those in the illustration on page 1.
Ice Tray
Fill tray 3 / full to allow expansion of water during freezing. Place tray in
4
freezer chest. To release cubes, twist lid slightly.
Shelf
Both shelves can be removed by pulling forward. The shelf can be placed
in either of two (higher or lower) positions.
Vegetable Crisper
May be used for vegetable storage. Both the crisper and its cover are
removable for easy cleaning. Simply slide forward to remove.
CAUTION: 1. Confirm your voltage before inserting the power supply
cord into the socket.
2. Contact the earthing conductor to this unit with an
attachment earthing screw.
3. Don't make it spill to this unit.
4. Don't work with flammable spray, such as painting, near this unit.
5. Don't put ignitable materials, such as either, benzine, L .P .
Gas, alcohol, etc., into this unit.
6. Precaution to the leakage of any gas equiment near this unit.
7. Precaution not to hold on to the door of this unit by children.
8. Precaution not to reinsert the power supply cord within 5
minutes after release it from socket. If not, a trouble may
be occured to compressor.
2
