Service Manual
Refrigerator
Model: FR-170
Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : FR17000010
FR-171
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo FR-171
Summary of Contents for Daewoo FR-171
- Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.
-
Page 2: Table Of Contents
CONTENTS 1. Specification -----------------------------------------------------------------------------------------------1 2. External view ----------------------------------------------------------------------------------------------2 3. Wire diagram ---------------------------------------------------------------------------------------------3 4. Name of parts---------------------------------------------------------------------------------------------4 5. Refrigerant cycle diagram ----------------------------------------------------------------------------5 6. Machine room view and part list-------------------------------------------------------------------6 7. Main components ---------------------------------------------------------------------------------------7 8. Door color specification -------------------------------------------------------------------------------9 9. Exploded view and parts list ------------------------------------------------------------------------12... -
Page 3: Specification
1. SPECIFICATION MODEL NAME FR-170 FR-171 120g 120g Refirgerant R134a 105g 105g Cooling System Direct Cooling Refrigeration System Natural Cold-air Convection Defrost System Natural Freezer : Manual Start & Stop Defrost Operation Refrigerator : Auto Start & Stop Cold Control... -
Page 4: External View
2. EXTERNAL VIEWS FR-170 28.5 555.5 FR-171 28.5 555.5... -
Page 5: Wire Diagram
3. WIRE DIAGRAM THERMOSTAT WHITE IL HEATER BLUE BLACK P-RELAY LAMP SWITCH LAMP BROWN L/BLUE GN/YW PLUG COMPRESSOR... -
Page 6: Name Of Parts
8 Vegetable Box 9 Freezer Pocket 10 Egg Pocket 11 Butter Pocket 12 Bottle Pocket (S) 13 Bottle Pocket (L) 14 Adjust Foot FR-171 1 Freezer Shelf 2 Ice Box 3 Ice Tray 4 Temp Control Dial 5 Lamp Switch 6 Shelf... -
Page 7: Refrigerant Cycle Diagram
5. REFRIGERANT CYCLE DIAGRAM F EVAPORATOR HOT PIPE ARGON ARGON ARGON DRYER R EVAPORATOR COMP... -
Page 8: Machine Room View And Part List
6. MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME DRYER AS VIBRATIONPROOF GUM FOOT ADJ COMPRESSOR BOX POWER FIXTURE VAPORI PIPE SERVICE CEC COVER CASE VAPORI SWITCH P-RELAY AS SCREW TAPPING VIBRATIONPROOF MASS (A) CORD POWER... -
Page 9: Main Components
7. MAIN COMPONENTS 1. COMPRESSOR Refrigerant Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Comp. model FL17J-3 FL15J-2 SL19J-5 PL17J-4 SL19J-5 Part code 3951117330 3951115320 3954119380 3956117340 3954119380 Strating type RSIR RSIR RSIR RSCR RSIR Refrigerant R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz... - Page 10 POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011315000 CP-2PIN FOR EUROPEAN COUNTRY 401RA17200 CP-2PIN FOR OTHER COUNTRY 4006D17101 KP-30 FOR AMERICA 401PD17101 KP-211 FOR JAPAN & TAIWAN 3011300801 BP-3PIN 3011303010 #267 FOR CHILE 3011315310 FOR ISRAEL FOR U.K, MIDDLE ASIA 3011303050 BS-1363A...
-
Page 11: Door Color Specification
Normal PCM Normal PCM sheet lamina sheet bright PCM sheet lamina sheet bright PCM Part code PFDU2UD210 PFDU2UD125 FR-171 1. ASSEMBLY URETHAN FREEZER DOOR Refrigerant R134a Dull lamina High glossy High glossy Dull lamina High glossy High glossy Color type... - Page 12 COLOR TABLE 1. PCM type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) '97 BEIGE (BE215)
- Page 13 2. Lamina sheet type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) S/GOLD G/GREEN...
-
Page 14: Exploded View And Parts List
9. EXPLODED VIEW AND PARTS LIST 1. Exploded view... -
Page 15: Parts List
2. Parts list Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) FR-170 PART CODE PART NAME... - Page 16 FR-171 PART CODE PART NAME DESCRIPTION QUANTITY REMARK ASSY URT CAB 4018R30323 FIXTURE BOILD PE-HD 3010302420 BASE COMP 4001E09013 ABSORBER COMP NR-A 4001E09021 WASHER SPECL SPG T0.6 4001E09030 WASHER SPECL SPG T1.0 COMPRESSOR REFER TO # 7 DRYER AS REFER TO # 7...
