Daewoo FR-146 Service Manual
Hide thumbs
Also See for FR-146:
- Service manual (18 pages) ,
- Instruction manual (8 pages) ,
- User manual (4 pages)
Advertisement
Downloaded from Fridge-Manual.com Manuals
Service Manual
Refrigerator
MODEL : FR-146
FR-146R
FR-146RV
FR-147
FR-147R
FR-147RV
Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. : FR14600010
Mar. 2004
Advertisement
Table of Contents
Related Manuals for Daewoo FR-146
Summary of Contents for Daewoo FR-146
- Page 1 S/M No. : FR14600010 Service Manual Refrigerator MODEL : FR-146 FR-146R FR-146RV FR-147 FR-147R FR-147RV Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
-
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATION .......................2 2. EXTERNAL VIEW .....................3 3. WIRE DIAGRAM .......................4 4. NAME OF PARTS......................5 5. REFRIGERANT CYCLE DIAGRAM ................6 6. MACHINE ROOM VIEW AND PARTS LIST..............7 7. MAIN COMPONENTS ....................8 8. DOOR COLOR SPECIFICATION ................9 9. EXPLODED VIEW AND PARTSLIST ...............13 Downloaded from Fridge-Manual.com Manuals... -
Page 3: Specification
SPECIFICATION MODEL NAME FR-13 120g Refrigerant R134a 105g Cooling System Aluminum-embossed Plat ì Roll Bondî type Refrigeration System Natural Cold-air Convention Defrost System Natural Defrost Operation Manual start & Stop Cold Control Adjustable Dial Freezer Capacity Refrigerator Total Height External Dimension Width depth Net Weight... -
Page 4: External View
EXTERNAL VIEW Downloaded from Fridge-Manual.com Manuals... -
Page 5: Wire Diagram
WIRE DIAGRAM P-RELAY YELLOW COMPRESSOR THERMOSTAT LAMP LAMP SWITCH L/BLUE BROWN BLAC K L/BLUE BROWN PLUG Downloaded from Fridge-Manual.com Manuals... -
Page 6: Name Of Parts
NAME OF PARTS FR-146, 146R, 147, 147R 1 Evaporator 2 Drain Pan 3 Control Box 4 Plastic Coated Shelf 5 Rack 6 Magnetic Door Seals 7 Ice Tray 8 Usable Rack 9 Bottle Rack 10 Crisper 11 Slide Out Crisper... -
Page 7: Refrigerant Cycle Diagram
REFRIGERANT CYCLE DIAGRAM EVAPORATOR DRYER COMPRESSOR Downloaded from Fridge-Manual.com Manuals... -
Page 8: Machine Room View And Parts List
MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME PART NAME CABINET SUCTION PIPE WASHER *T REINFORCE *L PIPE CON ABSORBER REINFORCE *R BASE COMP WASHER *U COMPRESSOR BOLT HEX MACHINE SCREW DRYER P RELAY AS TAPPING SCREW CAPI TUBE POWER CORD Downloaded from Fridge-Manual.com Manuals... -
Page 9: Main Components
MAIN COMPONENTS 1.COMPRESSOR Refrigerant 100V/50,60 110V/60 115,120V/60 127V/60 220V/50 220V/60 230V/50 240V/50 Voltage Comp model DS22LCF1 DS22LCF1 DS22LCF1 DS22LCF1 DS22LCS8 DS22LCS8 DS22LCS8 DS22LCS8 Part Code 3951122X10 3951122X10 3951122X10 3951122X10 3954122X80 3954122X80 3954122X80 3954122X80 Start type RSIR RSIR RSIR RSIR RSIR RSIR RSIR RSIR... - Page 10 MAIN COMPONENTS POWER CORD SPECIFICATION SHAPE OF POWER CODE PART CODE DESCRIPTION REMARK 3011300321 CP-2PIN 4017J17101 CP-2PIN 4006D17101 KP-30 3011304520 DKP-301U 401PD17101 KP-211 3011316201 BP-3PIN 3011300971 FOR SWISS #267 3011303020 FOR OTHER CONURTY 3011316101 FOR ISRAEL 3011303901 FOR EUROPEAN&SAUDI 3011303921 FOR SINGAPORE BS-1363A 3011303040...
-
Page 11: Door Color Specification
DOOR COLOR SPECIFICATION 1. ASSEMBLY URETHAN DOOR R12, R134a Refrigerant Key type Non Key type TPYE Dull lamina High flossy High glossy Dull lamina High flossy High glossy Color Type Normal PCM Normal PCM Lamina sheet bright PCM sheet bright PCM Lamina sheet sheet Normal... - Page 12 DOOR COLOR SPECIFICATION 1. PCM t ype COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) '97 BEIGE (BE215) Downloaded from Fridge-Manual.com Manuals...
- Page 13 DOOR COLOR SPECIFICATION 2. Lamina sheet type COLOR CHIP COLOR NAME P/WITH (WH069) '94 L/GRAY (GY158) '95 L/GRAY (GY259) '94 M/GRAY (GY331) '95 M/GRAY (GY335) '97 M/GRAY (GY267) M. D/GRAY (GY750) N/BLUE (BL718) MINT GREEN (GN206) S/GOLD G/GREEN Downloaded from Fridge-Manual.com Manuals...
-
Page 14: Exploded View And Partslist
EXPLODED VIEW AND PARTS LIST 1. FR-146, 146R, 147, 147R Downloaded from Fridge-Manual.com Manuals... - Page 15 EXPLODED VIEW AND PARTS LIST CAUTION : In this Service Manual, some parts can be changed for improving their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List)in Service information Center(http://svc.dwe.co.kr) PART CODE PART NAME DESCRIPTION...
- Page 16 EXPLODED VIEW AND PARTS LIST 2. FR-146RV, 147RV Downloaded from Fridge-Manual.com Manuals...
- Page 17 EXPLODED VIEW AND PARTS LIST CAUTION : In this Service Manual, some parts can be changed for improving their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List)in Service information Center(http://svc.dwe.co.kr) PART CODE PART NAME DESCRIPTION...
- Page 18 DAEWOO ELECTRONICS Corp. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA Downloaded from Fridge-Manual.com Manuals...
