NAMES OF THE PARTS

4 10
11 2 1
7
1. EVAPORATOR
The heart of the refrigerator.
It evaporates the refrigerant fluid and thereby absorbs heat from the surrounding. Made of
pure aluminum.
2. DRAIN PAN (Use of Defrost Only)
Discards the water that drips of the evaporator when defrosting.
3. CONTROL BOX :
Regulates the operation of the motor and controls the inside temperature of the refrigerator.
4. SHELF
Has full width and can slide out.
5. RACK For butter, eggs, and small size goods.
6. MAGNETIC DOOR SEALS
Keeps the refrigerator virtually airtight all along the edge, but is nevertheless easy to open.
7. ICE CUBE TRAY Ice cubes are easy to remove from the tray.
8. USABLE RACK for cans or jars.
9. BOTTLE RACK for bottles, cans or jars.
10. CRISPER
for vegetables and fruits.
11. SLIDE OUT CRISPER COVER.
3
5
8
9
6
1
