- Page 1 S/M No. : FR11000011 Refrigerator Service Manual MODEL : FR - 110 (Revision Edition) DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr Nov. 2002...
-
Page 2: Table Of Contents
SAFETY AND PRECAUTIONS 1) For starters, be sure to check any chances of the leakage of electricity 2) You could handle a part in the vicinity of electricity after unplugging 3) You should put on rubber glovers to prevent an electric shock on operation test 4) Make sure the rated current, voltage, capacity before using an instrument 5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten 6) Be careful not to let water to permeate the electric part in the machine room... -
Page 3: Specification
1.SPECIFICATION 1. FR-110 Model Name FR-110 100g Refrigerant R134a Cooling System Aluminum embossed plate "Roll Bond" type Natural Cold-air Convection Refrigeration System Defrost System Natural Defrost Operation Manual Start & Stop Cold Control Adjustable Dial Freezer Capacity Refrigerator Total Height... -
Page 4: External Views
2.External Views... -
Page 5: Wire Diagram
3.Wire Diagram 1) For other country 2) Only for JAPAN CONTROL SWITCH CONTROL SWITCH GREEN GREEN YELLOW YELLOW IL HEATER BLUE BLUE LAMP LAMP DOOR DOOR SWITCH SWITCH COMPRESSOR COMPRESSOR WHITE GREY 100V 50/60Hz PLUG PLUG... -
Page 6: Name Of Parts
4.Name of Parts 1 Panel Table 2 Case Icing 3 Freezer Shelf 4 Box Control 5 Knob Control 6 Shelf 7 Cover Vegetable Case 8 Case Vegetable 9 Adjustable Foot 0 Pocket Bar (A) q Pocket Bar (B) w Pocket Bar (D) e Pocket Bar (C) -
Page 7: Refrigerant Cycle
5.Refrigerant Cycle F EVAPORATOR HOT PIPE ARGON ARGON ARGON DRYER R EVAPORATOR COMP... -
Page 8: Machine Room View And Parts
6.Machine Room View and Parts PART NAME PART NAME PART NAME DRYER AS VIBRATIONPROOF GUM CORD POWER COMPRESSOR BOX POWER FOOT ADJ PIPE SERVICE CEC COVER FIXTURE VAPORI SWITCH P-RELAY AS SCREW TAPPING CASE VAPORI VIBRATIONPROOF MASS (A) -
Page 9: Main Components
7.Main Components 1. COMPRESSOR Refrigerant Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz 220V/60Hz 230V/50Hz 240V/50Hz Comp. model FL17J FL15J-3 FL15J-1 SL17J-5 SL17J-5 Part code 3951117300 3951115330 3951115310 3954117380 3954117380 Strating type RSIR RSIR RSIR RSIR RSIR Refrigerant R134a Voltage 100V/50,60Hz 110V/60Hz 115, 120V/60Hz 127V/60Hz 220V/50Hz... -
Page 10: Cabinet And Door Color Specification
8.Cabinet and Door Color Specification 1. ASSEMBLY URETHAN FREEZER DOOR 1) Key type Refrigerant R134a Dull lamina High glossy High glossy Dull lamina High glossy High glossy Color type Normal PCM Normal PCM sheet lamina sheet bright PCM sheet lamina sheet bright PCM Part code PFDT1UB280 PFDT1UB010... -
Page 11: Exploded Views And Parts List
9.Exploded Views and Parts List 1.Exploded View... - Page 12 2) Parts list PART CODE PART NAME DESCRIPTION QUANTITY REMARK 3017404901 LINER ABS T3.0 3010603610 BRACKET *M HINGE SPC-T2.5 3017000900 EVA F PIPE AS AL ¯8.0 3017001000 EVA R PIPE AS AL ¯8.0 3010604010 BRACKET SENSOR AL T2.0 3013201200 HOSE DRAIN 3014401707 PIPE SUC AS DCUT1-0 ¯6.0...
- Page 13 PART CODE PART NAME DESCRIPTION QUANTITY REMARK 7112401211 SCREW TAPPING T1 TRS MFZN 4X12 7650602011 BOLT HEX 6B-1 MFZN 6X20 10G(085 HCFC) 3016801423 DRYER AS DOOR F PCM T0.5 3011707200 3010906101 CAP F DOOR *T 3010906201 CAP F DOOR *U 3017405000 LINER F DOOR ABS T1.5...
