S/M No. :
FR36000001
Service Manual
Model: FR-360, FR-390
 Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr
Sep. 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR-360 and is the answer not in the manual?

Questions and answers

Related Manuals for Daewoo FR-360

Summary of Contents for Daewoo FR-360

  • Page 1 S/M No. : FR36000001 Service Manual Model: FR-360, FR-390  Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    SAFETY AND PRECAUTIONS 1) For starters, be sure to check any chances of the leakage of electricity. 2) You could handle a part in the vicinity of electricity after unplugging. 3) You should put on rubber gloves to prevent an electric shock on operation test. 4) Make sure the rated current, voltage, capacity before using an instrument.

  • Page 3: Specification

    SPECIFICATION Model Name FR-360 FR-390 Cooling system Fan Cooling Convention Type Refrigeration System Air Forced Convention Defrost System Forced Fin-Evaporator Type Defrost Operation Automatic start & stop Cold Control Adjustable Dial Method GROSS GROSS Capacity (l) Freezer Refrigerator Total External...

  • Page 4: External Views

    EXTERNAL VIEWS 1. FR-360,390...

  • Page 5: Wiring Diagram

    WIRING DIAGRAM...

  • Page 6: Name Of Parts

    NAME OF PARTS 1 CASE ICING 9 LAMP COVER (SHADE R) 2 F SHELF (REMOVABLE) 10 COVER CASE VAGETB 3 FREEZER TEMPERATURE 11 CASE VEGETABLE CONTROL KNOB 12 FREEZER POCKET (TOP) 4 CASE ICE 13 FREEZER POCKET (BOTTOM) 5 CHILLED CASE DOOR 14 EGG POCKET (TOP) 6 CASE CHILLED 15 CASE EGG...

  • Page 7: Air Flow Diagram

    AIR FLOW DIAGRAM AIR CIRCULATION in the Freezer. FREEZER COMPARTMENT Cold air flow comes out from the upper hole and comes Do not put in any breakable into the lower hole in louver. bottle. FREEZER COMPARTMENT DOOR POCKET -18 C Do not store ice cream or frozen food for a long time.

  • Page 8: Refrugerant Cycle Diagram

    REFRIGERANT CYCLE DIAGRAM...

  • Page 9: Machine Room View And Part List

    MACHINE ROOM VIEW AND PART LIST PART NAME PART NAME CABINET AS SWITCH P-RELAY AS COVER CAB BAND RELAY BASE CAB AS BOX POWER AS PIPE HOT CORD POWER AS PIPE SUC AS HARNESS MAIN CASE VAPORI PIPE SUC CONN C-FAN MOTOR PIPE CONN A FIXTURE C MOTOR AS...

  • Page 10: Main Components

    MAIN COMPONENTS 1.COMPRESSOR REFRIGERANT 110/60 127/60 220~240/50 220V/60 VOLTAGE ( V/HZ) CL23YE-3 CL23YE-2 SL25YE-5 PL23YE-4 COMP MODEL 3957123A10 3957123A20 3954125A50 3956123A40 PART CODE CSIR CSIR RSIR RSCR STARTING TYPE REFRIGERANT(g) R134a REFRIGERANT 110 / 60 115 / 60 220~240/50 220V/60 VOLTAGE ( V/HZ) HEL23YG-3 HEL21YH-1...
  • Page 11 MAIN COMPONENTS 4. RUNNING CAPACITOR REFRIGERANT 110/60 127/60 220~240/50 220V/60 VOLTAGE ( V/HZ) 400EL15110 PART CODE 350VAC 5µF SPEC. R134a REFRIGERANT 110 / 60 115 / 60 220~240/50 220V/60 VOLTAGE ( V/HZ) 400EL15130 3016401110 400EL15110 PART CODE 230VAC 10ß µF 350VAC 4 µF 350VAC 5 µF SPEC.
  • Page 12 R134a REFRIGERANT SPEC (g) 3016806300 3016806400 PART CODE 11. FREEZER DOOR R-134a Assy F Door R-12 3010080300 FR-360, FR-390 3010080310 12. REFRIGERATOR DOOR R-134a R-12 Assy R Door Key Type Non Key Type Key Type Non Key Type 3010084100 3010081000...

  • Page 13: Power Cord

    POWER CORD...

  • Page 14: Part List And Exploded View

    PART LIST (FR-360, FR-390)  Caution : In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center (http://svc.dwe.co.kr)
  • Page 15 PART LIST (FR-360, FR-390) PART NAME PART DESCRIPTION QUANTITY REMARK PART CODE LOUVER AS 3018906100 INSU F LOUVER AS F-PS 3013327800 KNOB F LOUVER 3013401000 LOUVER F 3018905700 DUCT R MULTI AS 3016908700 DUCT R MULT 3016907900 THERMOSTAT PFN175D-01, BU274...
  • Page 16 POCKET F *T 3019016300 POCKET F *U 3019016400 CASE EGG 3011165800 POCKET EGG 3019016500 POCKET MULTI 3019016600 POCKET JUMBO 1 (FR-360) / 2 (FR-390) 3019016710 POCKET SM FR-360 Only 3019016800 ASSY F HANDLE 3012624310 HANDLE F 39-1 3012624300 DECORATOR F HANDLE A...
  • Page 17 EXPLODED VIEW...
  • Page 18 DAEWOO ELECTRONICS CO., LTD. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” FAX: 02) 360-8184 TEL: 02) 360-8183 E-mail : G7F00E@web.dwe.co.kr S/M NO. : FR36000001 PRINTED DATE: Sep. 2001...
