• RMC : (Default OFF)
Set RMC sentence ON or OFF.
• GGA : (Default ON)
Set GGS sentence ON or OFF.
• GLL : (Default OFF)
Set GLL sentence ON or OFF.
• GSA : (Default OFF)
Set GSA sentence ON or OFF.
• VTG : (Default OFF)
Set VTG sentence ON or OFF.
• GSV : (Default OFF)
Set GSV sentence ON or OFF.
D GPS-A Set mode
Enter GPS-A operation set mode by selecting "GPS-A" in
GPS TX mode, then push [ ](5)
to set unproto address, data extension, time stamp, GPS-A
symbol and comment.

GPS-A SET MODE

GPS-A SET MODE
r
UNPROTO ADD UNPROTO ADD
DATA EXTENS DATA EXTENS
TIME STAMP TIME STAMP
GPS-A SYMBO GPS-A SYMBO
COMMENT COMMENT
‡ . This set mode is available
GPS-A SET MODE GPS-A SET MODE
UNPROTO ADD UNPROTO ADD
DATA EXTENS DATA EXTENS
TIME STAMP TIME STAMP
r
GPS-A SYMBO GPS-A SYMBO
COMMENT COMMENT
MENU SCREEN OPERATION
D Unproto Address
56 characters address can be entered for unproto address.
q Push [ ](5)
‡ twice to enter the unproto address edit
mode.
w Rotate [DIAL]
† to select the desired character.
• The selected character blinks.
• Push [A/a](3) to change the character group from "AB" (alphabeti-
cal characters; capital letters), "ab" (alphabetical characters; lower
case letters), "12" (numbers) and " !" " (symbols) in sequence.
• Push [ ](6) to move the cursor right; push [ ](4) to move the
cursor left.
• Push [CLR](1) to erase the selected character, or push and
hold [CLR](1) for 1 sec. to erase all characters following the
cursor.
e Repeat step w until the desired unproto address is pro-
grammed.
r Push [ ](5) to program the unproto address and exit the
unproto address edit mode.
t Push [ ](4) to return to GPS-A SET MODE screen mode.

UNPROTO ADDRESS

UNPROTO ADDRESS
API92,DSTA API92,DSTA
R* R*
:SET :SET
:BACK :BACK :EDIT :EDIT
CLR:CLR CLR:CLR
12
UNPROTO ADDRESS UNPROTO ADDRESS
AB AB
PI92,DSTA
†PI92,DSTA
R* R*
:SET :SET CLR:CLR CLR:CLR
:SEL :SEL A/a:CHAR A/a:CHAR
:CUR :CUR
