DO NOT
use or place the transceiver in areas with tem-
peratures below -30°C or above +60°C, or in areas subject to
direct sunlight, such as the dashboard of a vehicle.
AVOID
operating the transceiver without running the vehi-
cle's engine. The vehicle's battery will quickly run out if the
transceiver is in transmission while the vehicle's engine OFF.
AVOID
placing the transceiver in excessively dusty envi-
ronments.
AVOID
placing the transceiver against walls. This will
obstruct heat dissipation.
AVOID
the use of chemical agents such as benzine or
alcohol when cleaning, as they damage the transceiver sur-
faces.
BE CAREFUL!
The transceiver will become hot when
operating continuously for long periods.
For U.S.A. only
CAUTION: Changes or modifications to this transceiver, not ex-
pressly approved by Icom Inc., could void your authority to operate
this transceiver under FCC regulations.

TABLE OF CONTENTS

IMPORTANT .................................................................................... i
EXPLICIT DEFINITIONS ................................................................. i
CAUTIONS ....................................................................................... i
TABLE OF CONTENTS .................................................................. ii
1 PANEL DESCRIPTION ........................................................... 1-5
I Front panel ............................................................................... 1
I Function LED ........................................................................... 2
I Programmable function keys .................................................... 3
2 OPERATION ............................................................................ 6-8
I Turning power ON .................................................................... 6
I Channel selection ..................................................................... 6
I Receiving and transmitting ....................................................... 7
D Transmitting notes ................................................................. 7
D Scrambler function ................................................................ 8
D User set mode ....................................................................... 8
3 CONNECTION AND MAINTENANCE .................................. 9-13
I Rear panel and connection ...................................................... 9
I Supplied Accessories ............................................................. 10
I Mounting the transceiver ......................................................... 11
I Optional UT-108 installation ................................................... 11
I Optional UT-109/UT-110 installation ...................................... 12
I Optional OPC-617 installation................................................. 12
I Antenna ................................................................................... 13
I Fuse replacement .................................................................. 13
I Cleaning ................................................................................. 13
4 OPTIONS ................................................................................... 14
ii
