Recording on an External Device
(REC OUT mode)
You can listen to one program source while recording a different
program source.
1
<ZONE2/3 / REC SELECT>
Press .
"ZONE2 SOURCE" is shown on the display.
ZONE2 SOURCE ZONE2 TUNER ····
RECOUT V. AUX ······ RECOUT TUNER
2
<SOURCE SELECT>
Turn until "RECOUT SOURCE"
is displayed.
The " " indicator lights.
3
<SOURCE SELECT>
Turn to choose the input source
to be recorded.
4
Play the program source.
For operating instructions, refer to the respective equipment's
operating instructions.
To record FM or AM broadcasts, select the broadcast (vpage
44).
5
Start recording.
For operating instructions, refer to the respective equipment's
operating instructions.
• To cancel, press <ZONE2/3 / REC SELECT>, then turn <SOURCE SELECT>
until "ZONE2 SOURCE" is displayed.
• Make a test recording before starting the actual recording.
• Signals are only output to the analog REC OUT connectors when
the digital signals input to the digital input connectors (OPTICAL/
COAXIAL) are PCM (2-channel) signals.
• Digital audio signals input to the HDMI connectors are not output
to the REC OUT connectors, so connect using the OPTICAL or
COAXIAL connectors.
• Sources selected with the REC OUT mode are output from ZONE2
as well.
• In the REC OUT mode, the remote control unit's ZONE2 mode
buttons cannot be operated.
NOTE
• Recordings you make are for your personal enjoyment and should
not be used for other purposes without permission of the copyright
holder.
• Input sources for which "Delete" is selected at "Source Delete"cannot
be selected.

Convenient Functions

ZONE2 V. AUX
RECOUT SOURCE

Channel Level

You can adjust the channel level either according to the playback
sources or to suit your taste, as described below.
1
CH SELECT
Press
FL
C
FR
SW
2
CH SELECT
Use ui or
The speaker that can be set switches each time one of the
buttons is pressed.
3
Use o p to adjust the volume.
b "OFF" can be set by pressing o when the subwoofer's volume is
set to –12 dB.
.
Channel Volume
0.0dB SR 0.0dB
0.0dB SBR 0.0dB
0.0dB SBL 0.0dB
0.0dB SL 0.0dB
Fader
FRONT : REAR
to select the speaker.

Fader Function

This function lets you adjust (fade) the sound from all the front or
rear speakers at once.
1
CH SELECT
Press .
2
CH SELECT
Press ui or to select "Fader".
3
Use o p to adjust the volume of the speakers.
(o: front, p: rear)
• The fader function does not affect the subwoofer.
• The fader can be adjusted until the volume of the speaker adjusted
to the lowest value is –12 dB.
