Installing the Interactive Display Frame Components on Your
Flat Panel
Before you can install your interactive display frame, install your flat panel on a wall or stand.
WARNING
Do not mount your flat panel on the wall or remove it from the wall if your interactive
display frame is attached to it.
To install the flat panel
Use the illustration below to determine the appropriate height for your flat panel.
57"
145 cm
Follow the instructions in your flat panel installation guide or your floor stand installation guide.
With the assistance of another person, mount the flat panel onto a wall mount or floor stand.
Your interactive display frame consists of four blocks and four bezels that install on a wall- or
stand-mounted flat panel. Perform the following steps to attach them to your flat panel.
WARNING • Failure to follow the installation instructions that shipped with your SMART Board
interactive display frame, including the installation of all the supplied fasteners,
could result in personal injury and damage to the product.
• Follow the instructions that came with your flat panel, and ensure that you
comply with all the manufacturer's safety warnings.
• SMART recommends that you do not use a table stand with the
interactive display frame.
• To prevent personal injury or damage to the product, ensure that you install all of
the fasteners as instructed.
Installing Your SMART Board interactive display frame
39"
99 cm
