  • Page 1 1620 User's Manual Manual del Usuario iAMP 3020...
  • Page 2 1620 iAMP 3020 DIGITAL AMPLIFIER AMPLIFICADOR DIGITAL ENGLISH ........I ESPAÑOL .

  • Page 3: Table Of Contents

    USER'S MANUAL CONTENTS INTRODUCTION FEATURES FRONT PANEL BACK PANEL SPECIFICATIONS APPENDIX APPLICATIONS DIMENSIONS BLOCK DIAGRAMS Phonic preserves the right to improve or alter any information within this document without prior notice iAMP1620 / iAMP3020...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The apparatus shall not be exposed to dripping or splashing and that no objects with liquids, such as vases, shall be placed on the apparatus. The MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

  • Page 5: Introduction

    INTRODUCTION FRONT PANEL Congratulations on your purchase of another great Phonic product. Gain Controls The iAMP1620 and iAMP3020 were carefully designed so as to These controls adjust the incoming level received by the respec- provide phenomenal power in a low-weight, easily-manageable tive channel 1 and channel 2 input jacks on the rear of the iAMP.

  • Page 6: Back Panel

    Due to the heat that can be accumulated when amplifying signals, concentrate on these frequencies and thus improving the level of Phonic includes a variable-speed fan that is temperature sensitive bass and your overall ‘thump’. – activated and deactivating as necessary.

  • Page 7: Specifications

    SPECIFICATIONS iAMP 1620 iAMP 3020 Output Per Channel 1KHz, 0.5% THD Output Power 8 ohms 600W 1200W Output Power 4 ohms 1060W 2000W Output Power 2 ohms 1600W 3000W 0.775 volts +/- 3% for 1 kHz 4 ohm rated power, Input Sensitivity 0.68 volts +/- 3% for 1 kHz.

  • Page 8: Service And Repair

    Phonic, at its option, shall repair or replace the defective unit covered by this warranty. Please retain the dated sales receipt as evidence of the date of purchase.
  • Page 9 Manual del Usuario CONTENIDO INTRODUCCIÓN CARACTERÍSTICAS PANEL FRONTAL PANEL POSTERIOR ESPECIFICACIONES APÉNDICE APLICACIONES DIMENSIONES DIAGRAMAS DE BLOQUE Phonic se reserva el derecho de mejorar o alterar cualquier información provista dentro de este documento sin previo aviso. iAMP1620 / iAMP3020 iAMP1620 / iAMP3020...
  • Page 10 iAMP1620 / iAMP3020...

  • Page 11: Introducción

    PANEL FRONTAL Felicitaciones por la compra de otro fantástico producto de Ganancias de Controles Phonic. Los iAMP1620 y iAMP3020 han sido meticulosamente Estos controles ajustan los niveles de entrada recibidos por las diseñados para brindarle una potencia fenomenal en peso liviano, entradas jacks del panel posterior del iAMP del respectivo canal construcción fácil administrable de rack montable.

  • Page 12: Panel Posterior

    100 Hz para usos de altavoces de frecuencia el disyuntor es activado nuevamente, le sugerimos en que se media-alta. ponga en contacto con su distribuidora Phonic de su país para reparaciones y servicios. Gama-Completa: Esta posición permitirá que todas las frecuen- cias pasen mediante el amplificador;...

  • Page 13: Especificaciones

    ESPECIFICACIONES iAMP 1620 iAMP 3020 Salida por Canal 1KHz,0.,5%THD Salida de Potencia 8 ohms 600W 1200W Salida de Potencia 4 ohms 1060W 2000W Salida de Potencia 2 ohms 1600W 3000W 0.775 voltios +/- 3% por 1 kHz 4 ohm potencia nominal, Entrada de sensibilidad 0.68 voltios +/- 3% por 1 kHz.
  • Page 14 Phonic, a su propia opinión, reparará o cambiará la unidad defectuosa que se encuentra dentro de esta garantía.
  • Page 15 APPLICATIONS APLICACIONES KEYBOARD STEREO OPERATION TECLADO OPERACIÓN ESTÉREO GUITAR GUITARRA AM442D GUITAR EFFECTS EFECTOS DE GUITARRA CD or MP3 PLAYER REPRODUCTOR ACTIVE MONITOR CD O MP3 MONITORES ACTIVOS CD MP3 MICROPHONES MICRÓFONOS MAIN OUT SALIDA PRINCIPAL iAMP1620 PASSIVE SPEAKER ALTAVOCES PASIVOS ADDITIONAL AMPLIFIERS AMPLIFICADORES ADICIONALES iSK12...
  • Page 16 DIMENSIONS DIMENSIONES 482 / 19 88 / 3.5 measurements are shown in mm/inches Todas las medidas están mostradas en mm/pulgadas. iAMP1620 / iAMP3020...
  • Page 17 BLOCK DIAGRAM DIAGRAMA DE BLOQUE iAMP1620 / iAMP3020...
