Generac Power Systems 004373-1, 004626-0 Owner's Manual page 43

(Model Nos. 004373-0 & 004626-0) Guardian Liquid-cooled 40 kW Generators
ITEM PART NO. QTY. DESCRIPTION
1 051768 6
2 051769 6
3 022237 8
4 043097 8
5 0A3852 3
6 055173 6
7 022129 6
9 0A5526 1
10 0A2601 1
11 0A2602 1
12 0A1138 1
13 021941 1
14 020808A 1
15 052624 1
16 070892 1
17 065477 4
18 0A1633 4
19 020729A 1
20 022131 12
21 046526 12
22 057642 12
SCREW HHC M12-1.75 X 25 G8.8
WASHER LOCK M12
WASHER LOCK 3/8
SCREW SHC 3/8-16 X 1 G8.8 NZ
PLATE FLEX GM
SCREW HHC M8-1.25 X 20 G10.9
WASHER LOCK M8-5/16
FAN ASSEMBLY 390 SAE DD
SCREW HHC M16-2.0 X 45 G8.8
WASHER FLAT .688 ID X 3.25 OD
KEY SQ 3/8 X 2-1/2 STEEL
COUPLER 390 SAE
ROTOR 390 40 1P DIRECT
BEARING BALL 6212 SEALED
SLIP RING -MACHINED-
SCREW HHC M14-2.0 X 150 G8.8
WASHER 390 SAE ALT
STATOR 390 40AD2 SAE
WASHER FLAT 3/8-M10 ZINC
WASHER LOCK M10
SCREW HHC M10-1.5 X 40 G8.8
Section 7 — Exploded Views and Parts Lists
Generator – Drawing No. 0D5333-A
ITEM PART NO.
23 068113
24 068115
25 043123
26 051779
27 046852
28 022250
29 051769
30 057821
31 022145
32 022129
33 057821
34 024044A
35 023877D
36 022155
37 025105
38 071639
39 0A4089
40 0A2437
41 022473
42 056326
QTY. DESCRIPTION
1 CARRIER REAR BEARING 15"
1 LOWER PANEL 15
4 WASHER LOCK M14
4 NUT HEX M14-2.0 G8 YEL CHR
1 SCREW HHTT #10-32 X 1/4 BP
1 WASHER FLAT 7/16
1 WASHER LOCK M12
1 SCREW HHC M8-1.25 X 40 G8.8
1 WASHER FLAT 5/16 ZINC
1 WASHER LOCK M8-5/16
4 SCREW HHC M8-1.25 X 40 G8.8
2 ASSEMBLY BRUSH & SHUNT
4 BRUSH HOLDER-UNIV
4 WASHER LOCK #6
4 SCREW RHM 6-32 X 1/4 SIMS
1 HOLDER BRUSH SUPPORT
1 ASSEMBLY SCROLL 390 SAE
2 SCREW SWAGE 1/4-20 X 5/8 Z/YC
2 WASHER FLAT 1/4 ZINC
8.4' TRIM VINYL BLACK 1/8 GP
Generac Power Systems, Inc. 41
®
