  • Page 1: Quick Setup Guide

    KD-MSWCAT4x4 KD-MSWCAT8x8 Component/VGA with Audio via CAT5 Matrix Switchers Quick Setup Guide KD-MSWCAT4X4 KD-MSWCAT8X8 Key Digital FatBoy Series KD-MSWCAT8X8 and 4X4 are VGA/Component ® ™ Matrix Switchers capable of handling up to 8 or 4 RGBHV/Component Video Sources/Inputs to 8 or 4 Independent Zones/Outputs via CAT5 Cables...

  • Page 2: Table Of Contents

    . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Full integration with Key Digital KD-VACRX and KD-VACWPRX Balun products »...

  • Page 3: Connections, Leds And Button Map

    6. Power Connection 6v - 6 . 6 A . Please use included power adapter . You MUST use the Power Supply provided with your unit or you VOID the Key Digital Warranty and risk damage to your unit ®...

  • Page 4: Application Example

    Page 4 Page 5 Front Panel Operation Quick Setup Guide Begin with the KD-MSWCAT8X8 and all input/output devices turned off with power cables removed Connect CAT5 outputs located on the lower row of jacks to KD-VACRX or KD-VACWPRX 1. Output buttons 1-8 Baluns at display or receiving devices .

  • Page 5: Kd-Mswcat4X4

    » 3 breakout cable (for Component and included for Receiver Baluns all inputs) Full integration with Key Digital KD-VACRX and KD-VACWPRX Balun products » Full Audio control per output for Volume, Treble, Bass, Balance, and Lip-Sync (Delay) » 2. 2 X 3.5mm Audio connections for balanced or Serial IR, Optical IR, Front Panel Control, Discrete Remote Codes, and RS-232 .

  • Page 6: Application Example

    Audio Inputs sequentially from 1-4 . You MUST use the Power Supply provided with your unit or you VOID For switching inputs, simply press the the Key Digital Warranty and risk damage to your unit and associated ® ‘Input Select’ button within the desired Output section . Pressing this button repeatedly will cycle equipment.

  • Page 7: Quick Setup Guide

    Page 10 Page 1 1 All Mute Balance LipSync All Restore All Mute Balance LipSync Mute Restore Mute Quick Setup Guide Volume Level To adjust the Output Volume for a specific Output number: Select the desired Output number, Begin with the KD-MSWCAT4X4 and all input/output devices turned off with power cables press the ‘Volume’...

  • Page 8: Rs-232 Commands And Protocol

    Page 12 Page 13 RS-232 Commands and Protocol Specifications The KD-MSWCAT8X8/4X4 provides access to all functions when used with an RS-232 control ½ Technical: system . » Inputs: 4 or 8 RGBHV or YPrPb on a single 15 pin female connector 1Vpp/75Ω . Stereo Analog balanced KD-MSWCAT4X4 is compatible with all Control Systems, such as AMX , Colorado vNet ®...

  • Page 9: Troubleshooting

    Damage to the power supply or power plug » Exposure to rain or moisture » You MUST use the Power Supply provided with your unit or you VOID the Key Digital Warranty and risk damage to your unit and associated equipment. ®...

  • Page 10: How To Contact Key Digital

    For marketing and public relations information, please contact us at: Phone: 914-667-9700 ½ E-mail: marketing@keydigital .com ½ Repairs and Warranty Service Should your product require warranty service or repair, please obtain a Key Digital ® Return Material Authorization (RMA) number by contacting us at: Phone: 914-667-9700 ½...
  • Page 11 ® develops and manufactures high quality, cutting-edge technology solutions for virtually all applications where high quality video imaging is important . Key Digital ® is at the forefront of the video industry for Home Theater Retailers, Custom Installers, System Integrators, Broadcasters, Manufacturers, and Consumers .
