KDMSW8x4Pro_Manual.qxd
1/17/07
10:54 AM
KD-MSW8x4Pro Operating Instructions
521 East 3rd Street, Mount Vernon, NY 10553
Phone:
914.667.9700
Fax:
914.668.8666
Page 1
Key Digital
, led by digital video pioneer Mike Tsinberg,
®
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital
at the forefront of the video industry for Home Theater
Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers. We pro-
vide total video system solutions because we know and
help drive the technology, the industry, the business,
and all the latest up-and-coming standards. But most
of all, we know exactly what you need for your unique
application - the right solution.
Rev 0 - January 2007
Web:
www.keydigital.com
KD-MSW8x4Pro
HDTV Matrix Switcher
8 Inputs to 4 Outputs HDTV Matrix Switcher with Volume Control
OPERATING INSTRUCTIONS
These Operating Instructions apply to the entire
Key Digital
KD-MSW8x4Pro . . . . . . . . . . . . . . . . . . . . . .8x4 HDTV Matrix Switcher (single base unit)
KD-MSW8x4Pro - 8x8 . . . . . . . . . . . . . . . . .8x8 HDTV Matrix Switcher (2 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x12 . . . . . . . . . . . . . . . .8x12 HDTV Matrix Switcher (3 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x16 . . . . . . . . . . . . . . . .8x16 HDTV Matrix Switcher (4 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x20 . . . . . . . . . . . . . . . .8x20 HDTV Matrix Switcher (5 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x24 . . . . . . . . . . . . . . . .8x24 HDTV Matrix Switcher (6 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x28 . . . . . . . . . . . . . . . .8x28 HDTV Matrix Switcher (7 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x32 . . . . . . . . . . . . . . . .8x32 HDTV Matrix Switcher (8 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x36 . . . . . . . . . . . . . . . .8x36 HDTV Matrix Switcher (9 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x40 . . . . . . . . . . . . . . . .8x40 HDTV Matrix Switcher (10 base units of 8x4 and Cable Kit)
KD-MSW8x4Pro - 8x44 . . . . . . . . . . . . . . . .8x44 HDTV Matrix Switcher (11 base units of 8x4 and Cable
The KD-MSW8x4Pro by Key Digital
non-blocking switcher and distribution amplifier allows each one of the 4 outputs to be seamlessly connected to any
is
®
one of the 8 available inputs. The KD-MSW8x4Pro offers the factory installed expansion capability to up to 44 outputs
and professional Fade-to-Black and Audio/Video Muting features. It directly supports component (YPbPr) and RGBHV
video formats, as well as S-Video and Composite video formats (with appropriate cable adapters). Concurrently with
the video, it switches and distributes both PCM coaxial digital audio and analog stereo audio (analog stereo audio is
not available when RGBHV configuration is used). The KD-MSW8x4Pro features volume control functionality for ana-
log stereo audio L/R channels. With analog video bandwidth of up to 300 MHz, the KD-MSW8x4Pro handles all stan-
dard HD and SD video resolutions (at 50 and 60 Hz) including 1080p/60, with no degradation in video quality.
The KD-MSW8x4Pro is simple to operate and control via front panel puttons. The LEDs offer selection monitoring.
The switcher is offered with IR remote control, wired IR and RS-232 control port compatible with all industry standard
control systems.
Only operate the KD-MSW8x4Pro HDTV Matrix Switcher Series with the Key Digital
external Power Supply provided with your unit.
®
Fat Boy Series line of HDTV Matrix Switchers:
®
is a part of Fat Boy family of switchers. With 8 Inputs and 4 Outputs, the full matrix
Kit)
®
