3-4
There will be no guaranty for the settings beyond specification, any damage of any component on this
motherboard or peripherals result therein is not our responsibility.
! CPU FSB Clock(MHz):
This item selects the external clock frequency. Due to the specification limit of the CPU you installed, the
speed you set over its standard bus speed is supported, but not guaranteed.
!
Multiplier Factor:
This item displays the multiplier factor for the CPU you installed.
AGP Clock(MHz):
This item allows you to set the AGP clock speed from 66MHz to 100MHz. Due to the AGP specification
limit, the speed you set over its standard clock speed is supported, but not guaranteed.
Voltage Control:
This option allows you to switch between the default and user-defined voltages. Leave this setting to
default unless the current voltage setting cannot be detected or is not correct. The option "User Define"
enables you to select the following voltages manually.
! CPU Core Voltage:
This item selects the CPU core voltage.
! DDR RAM Voltage:
This item selects the voltage for DRAM slot.
! DDR Ref Voltage:
This item selects the reference voltage needed for DRAM slot to increase its conformity.
! AGP Voltage:
This item selects the voltage for AGP slot.
! nForce3 Voltage:
This item selects the Chipset voltage.
!
HyperTransport Voltage:
This item selects the voltage for LDT Bus.
ATTENTION: A wrong voltage setting may cause the system unstable or even damage the CPU. Please
leave it to default settings unless you are fully aware of its consequences.
NF8 Series
Chapter 3
