Specifications

Accuracy
Parameter
Voltage
iFlex1500-12
iFlex3000-24
Current:
Direct input
iFlex6000-36
i40s-EL clamp
Frequency
Aux input
Voltage Min/Max
Current Min/Max
Cosϕ/DPF
Power factor
THD on voltage
THD on current
Intrinsic uncertainty ± (% of reading + % of range)
Parameter
Active power P
Apparent power S, S fund.
Reactive power N, Q fund.
Additional uncertainty in %
1
of range
1
Range = 1000 V x Irange
Reference conditions:
Environmental: 23 °C ± 5 °C, instrument operating for at least 30 minutes, no external electrical/magnetic field, RH <65 %
ϕ
Input conditions: Cos /PF=1, Sinusoidal signal f=50 Hz/60 Hz, power supply 120 V/230 V ±10 %.
Current and power specifications: Input voltage 1 ph: 120 V/230 V or 3 ph wye/delta: 230 V/400 V
Input current: I > 10 % of Irange
Primary conductor of clamps or Rogowski coil in center position
Temperature coefficient: Add 0.1 x specified accuracy for each degree C above 28 °C or below 18 °C
3 Fluke Corporation Fluke 1730 Three-Phase Electrical Energy Logger
Shop for Fluke products online at:
Range Resolution
1000 V 0.1 V
150 A 0.1 A
1500 A 1 A
300 A 1 A
3000 A 10 A
600 A 1 A
6000 A 10 A
4 A 1 mA
40 A 10 mA
42.5 Hz to 69 Hz 0.01 Hz
± 10 V dc 0.1 mV
1000 V 0.1 V
defined by defined by
accessory accessory
0 <= Cosϕ <=1 0.01
0 <= PF <=1 0.01
1000 % 0.1 %
1000 % 0.1 %
1
Influence iFlex1500-12
quantity
150A/1500A
PF ≥ 0.99 1.2 % +
0.005 %
0.5 <PF <0.99 1.2 % + 7 x
(1-PF)
+0.005 %
0 ≤ PF ≤ 1 1.2 % +
0.005 %
0 ≤ PF ≤ 1 2.5 % of measured apparent power
U >250 V 0.015 %
