Fluke 1730/BASIC Technical Data Manual

Fluke 1730
Three-Phase Electrical
Energy Logger
Energy logging is now within your reach—
discover where you're wasting energy, optimize
your facility's energy use and reduce your bill.
The new Fluke 1730 Three-Phase Electrical Energy logger
introduces a new simplicity to discovering sources of
electrical energy waste. Discover when and where
energy in your facility is being consumed; from the
service entrance to individual circuits. Profiling energy
usage across your facility helps you identify opportunities
for energy savings, and provides you with the data you
need to act on them. The new Energy Analyze software
package allows you to compare multiple data points over
time to build a complete picture of energy usage, which
is the first step to reduce the cost of your energy bill.
• Key measurements: voltage, current, power,
power factor and associated values enable
energy saving strategies to be implemented.
• Bright, color touch screen: perform conve-
nient in-the-field analysis and data checks
with full graphical display.
• Comprehensive logging: all measured values
are automatically logged and can be reviewed
during logging and before downloading for on-
the-go analysis. More than 20 separate logging
sessions can be stored on the instrument.
• Optimized user interface: quick, guided,
graphical setup ensures you're capturing the
right data every time, and the intelligent veri-
fication function indicates correct connections
have been made, reducing user uncertainty.
• Complete 'in-the-field' setup through the
front panel: no need to return to the workshop
for download and setup or to take a computer
to the electrical panel.
Shop for Fluke products online at:
• Wide range power: power instrument directly
from the measured circuit eliminating the
need to find a power outlet while allowing the
instrument to be secured safely inside electri-
cal panels.
• Two USB ports: one for PC connection and
another for fast, simple download to standard
USB thumb drives, or other USB devices.
• Compact size: designed to fit in tight spaces
and panels.
• Highest safety rating in the industry: 600 V
CAT IV/1000 V CAT III rated for use at the ser-
vice entrance and downstream.
• Optimized measurement accessories: flat
voltage cable and thin flexible current probes
ensure easy installation even in tight spaces.
• Battery life: four-hour operating time (backup
time) per charge on lithium-ion battery.
• Security: safeguard against theft with a
Kensington lock.
• All new, Energy Analyze application soft-
ware: download, analyze and automated
reporting for a complete picture of energy
saving potential.
