Summary of Contents for AEG Electrolux EOG 1710
- Page 1 Gas oven - Einbau Gas-Backofen INSTRUCTION BOOKLET GEBRAUCHSANLEITUNG Mod. EOG 1710 35689-8702...
-
Page 3: Important Safety Information
English Important Safety Information These warnings are provided in the interest of your safety. You MUST read them carefully before installing or using the appliance. Installation • Do not hang towels, dishcloths or clothes from the oven • This oven must be installed by qualified personnel in or its handle. -
Page 4: Table Of Contents
Contents For the User For the Installer Important Safety Information Description of the Appliance Instructions for the Installer Controls Building in Before the First Use Electrical Connection Using the Oven Gas connection Turnspit Adaptation to different types of gas Using the Traditional Gas Oven Using the Fan Gas Oven Grilling Cleaning the Oven... -
Page 5: Description Of The Appliance
Description of the Appliance 1. Control panel 2. Minute minder 3. Light, Grill & Fan control knob 4. Gas oven control knob 5. Grill control light 6. Mains on light 7. Grill 8. Oven lamp 9. Oven fan 10. Oven cavity bottom plate 11. -
Page 6: Before The First Use
Grill Control Light The Grill (thermostat) control light will come on when the thermostat control knob is turned. The light will remain on until the correct temperature is reached. It will then cycle on and off to show the temperature is being maintained. Gas Oven Control Knob Oven burner off 150 - 240... -
Page 7: Using The Oven
Using the Oven Always cook with the oven door closed. The oven is supplied with an exclusive system which produces a natural circulation of air and the constant recycling of steam. This system makes it possible to cook in a steamy environment and keep the dishes soft inside and crusty outside. -
Page 8: Turnspit
Turnspit To use the turnspit, proceed as follows: 1. Insert the spit frame on the second guide from the bottom, as shown in the figure. 2. Insert the first fork in the spit, skewer the food to be cooked and secure it by inserting the second fork;... -
Page 9: Using The Traditional Gas Oven
Using the Traditional Gas Oven During cooking, the door should be opened as little Cooking Chart as possible to avoid heat loss, and excessive fuel consumption. TEMP. SHELF COOKING FOOD (°C) POSITIONS TIME To ignite the oven gas burner: MEAT & POULTRY 1. -
Page 10: Using The Fan Gas Oven
Using the Fan Gas Oven Cooking Chart The air inside the oven is heated by the gas burner and the fan circulates hot air to maintain an even temperature inside the oven. TEMP. SHELF COOKING FOOD (°C) POSITIONS TIME The advantage of cooking with this function is MEAT &... -
Page 11: Grilling
Grilling Cooking chart Grilling must be carried out with the oven door closed. Cooking time depends on the thickness of the meat and not on its weight. How to Use the Grill 1. Turn the “Light-Grill & Fan” clockwise control knob after symbol . -
Page 12: Cleaning The Oven
Cleaning the Oven Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply. This appliance cannot be cleaned with steam or with a steam cleaning machine. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. -
Page 13: Replacing The Oven Light
Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner. -
Page 14: Something Not Working
Something Not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 15: Instructions For The Installer
Instructions for the Installer Technical Data Cabinet Dimensions Minimum aperture height APPLIANCE GAS SUPPLY: Natural Gas G20 20 mbar undertop: 593 mm APPLIANCE CATEGORY:II2H3B/P in column: 580 mm Minimum aperture depth 550 mm Oven Minimum aperture width 560 mm Oven burner 2700 W (Natural gas G20) 2500 W (Liquid gas G30/G31) Dimensions of the oven cavity... -
Page 16: Building In
Building in Location of appliance The appliance may be located in a kitchen, a kitchen/ diner or bedsitting room but not in a bathroom, shower room or bedroom. It is essential that there is a minimum clearance of 4mm between the top surface of the appliance and the inside top of the cabinet. -
Page 17: Electrical Connection
Securing the oven to the cabinet 1. Fit the oven into the cabinet recess 2. Open the oven door 3. Secure the oven to the kitchen cabinet with four wood screws, which fit the holes provided in the oven frame (see diagram). Electrical Connection The instructions given below are designed Terminal block... -
Page 18: Gas Connection
Gas connection Connecting the appliance to the gas supply View flexible from metallic pipe above The gas supply connection ramp is located in the upper side of the oven, right behind the control panel. gasket To carry out the gas connection: 1. -
Page 19: Adaptation To Different Types Of Gas
Adaptation to different types of gas IMPORTANT The replacement/conversion of the gas hob should only be undertaken by qualified personnel. It is important to note that this model is designed for use with natural gas at a feeding pressure of 20 mbar but can be converted for use with LPG providing the correct injectors are fitted. - Page 20 Minimum level adjustment of gas oven burner This procedure must be undertaken by qualified personnel only. Disconnect the appliance from the electricity supply. 2. Remove all the knobs. 3. Open the oven door and locate the ventilation grid which is fixed right below the control panel. 4.
- Page 21 EUROPEAN GUARANTEE This appliance is guaranteed by Electrolux in each of the countries listed below for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications:- •...
