Full D1 Outdoor H.264 Day/Night
IP Camera
IR-210B / IR-210P
Outdoor H.264 Day/Night IP
Camera
IP66
IR 30M

Product Overview

This IR-210B/IR-210P features
l a t e s t H . 2 6 4 c o m p r e s s i o n t o
optimize image quality, and lower
n e t w o r k b a n d w i d t h a n d s t o r a g e
c a p a c i t y r e q u i r e m e n t s . D u r a b l e
and weatherproof, the camera is
designed to operate in harsh outdoor
environments. IR-210B/IR-210P is
easy to set up and produce crystal
clear high resolution video day or
night, indoors or out. The Sony CCD
offers up to 30fps at full D1 resolution
for great light sensitivity and the ability
to multi-stream H.264, MPEG4, or
MJPEG video image at 30 fps. The IR-
210B is integrated with EDIMAX NVR
and CMS video management solutions.
IP Surveillance Series / IP Camera / CCD / IR / Bullet /

Specifications

IR-210B Full D1 Outdoor H.264 Day/Night IP Camera

Description

IR-210P Full D1 Outdoor H.264 Day/Night PoE IP
Camera
IR-LED
12 pcs LED ; 850nm ; 30M
Sensor
1/3" Sony Super HAD CCD II
Processor
Next Chip NVP2040 + DaVinci TM320DM365

Lens

Fixed Lens 6mm/8mm /12mm

Min. Illumination

0.05 Lux / F1.2

Video Compression

H.264 HP/MP/BP, MPEG-4 SP, M-JPEG
600 TVL(Horizontal)
D1(720x480) :30 fps

Resolution

VGA(640x480):30fps
QVGA(320x240):30fps
QCIF(176x144):30fps
Multiple Streaming
Yes
SD/SDHC interface
Yes (option)
Power-over-
Ethernet
IR-210P
(IEEE 802.3af)
Two-way Audio
Two-way
Support
Alarm Input/
1x D/I, 1x D/O
output
Digital zoom
10x
ONVIF
Yes
TCP/IP,IPV6,UDP,ICMP ,DHCP ,NTP ,DNS ,DDNS ,SMTP

Protocol

,FTP ,HTTP ,HTTPs ,Samba,PPPoE ,UPnP, Bonjour, RTP,
RTSP, RTCP, IPV4
QoS
Yes
Multi-level user
Yes
access
IP filtering
Yes
3GPP support
Yes
Manual Time Setting
Time Management
Time Server and NTP support
Real Time Clock
Events Triggered by Motion detection or GPIO
Event Management
Image or Video Upload/Send over email ,FTP, samba
Recording Video file to SD Card by schedule
System
64CH Management Software(EdiView RS-64)
Management
Operation
0~50
Temperature
Approvals
CE, FCC

Dimension

130 mm (D) x 72 mm (W) x 58 mm (H)

Weight

400g
Package
Accessories: Power Supply ; CD
IR-210B . IR-210P
»
Super image quality using Sony
CCD, producing 600 lines of
resolution
»
Deliver up to 30 FPS high res
de-interlaced video @ full D1,
720x480
»
Featuring H.264 compression
technology for optimized image
quality, and lower bandwidth
and storage requirements
»
Advanced features include
digital slow shutter and motion
detection
o
C
9
