AEG 24" HK654070XB User Manual

AEG 24" HK654070XB User Manual

24” electric cooktop
Hide thumbs Also See for 24" HK654070XB:


User's Manual
HK654070XB 24" Electric Cooktop -
User's Manual
Table of Contents

Summary of Contents for AEG 24" HK654070XB

  • Page 1 User’s Manual HK654070XB 24” Electric Cooktop - User’s Manual...
  • Page 2 Please spend a few minutes reading to get the very best from it. ACCESSORIES AND CONSUMABLES In the AEG webshop, you’ll find everything you need to keep all your AEG appliances looking spotless and working perfectly. Along with a wide range of accessories...
  • Page 3: Table Of Contents

    Contents CONTENTS 4 Safety information 5 Installation instructions 7 Product description 8 Operating instructions 12 Helpful hints and tips 13 Care and cleaning 14 What to do if… 15 Environment concerns 15 Warranty The following symbols are used in this user manual: Important information concerning your personal safety and information on how to...
  • Page 4: Safety Information

    Safety information SAFETY INFORMATION For your safety and correct operation of the appliance, read this manual carefully before the installation and use. Always keep these instructions with the appliance also if you move or sell it. The users must fully know the operation and safety functions of the appliance. Children and vulnerable people safety WARNING! Do not let persons, children included, with reduced physical sensory, reduced mental func-...
  • Page 5: Installation Instructions

    Installation instructions • Do not put the aluminium foil on the appliance. WARNING! If there is a crack on the surface, disconnect power supply to prevent the electrical shock. INSTALLATION INSTRUCTIONS Before the installation, note down the serial number (Ser. Nr.) from the rating plate.The rating plate of the appliance is on its lower casing.
  • Page 6 Installation instructions • Install correctly to give shock protection. • Loose and incorrect plug and socket connections can make the terminal become too hot. • A qualified electrician must install the connections in the clamps correctly. • Use a strain relief clamp on cable. •...
  • Page 7: Product Description

    Product description If you use a protection box (the additional acces- sory), the protective floor directly below the appli- ance is not necessary. PRODUCT DESCRIPTION General overview Single cooking zone 1200 W Oval zone 1500/2400 W Single cooking zone 1200 W Control panel Triple cooking zone 800/1600/2300 W Control panel layout...
  • Page 8: Operating Instructions

    Operating instructions sensor field function It activates Automatic Heat Up function. It activates and deactivates the outer ring. A heat setting display It shows the heat setting. A control bar To set the heat setting. It increases or decreases the time. It sets the cooking zone.
  • Page 9: The Heat Setting

    Operating instructions • You spill something or put something on the control panel for more than 10 seconds, (a pan, a cloth, etc.). The sound operates some time and the appliance deactivates. Remove the object or clean the control panel. •...
  • Page 10 Operating instructions 2. Immediately touch the necessary heat setting. After 3 seconds comes on in the dis- play. To stop the function change the heat setting. Timer Count Down Timer Use the Count Down Timer to set how long the cooking zone operates for only this one time.
  • Page 11: The Child Safety Device

    Operating instructions STOP+GO function sets all cooking zones that operate to the lowest heat setting ( When operates, you cannot change the heat setting. function does not stop the timer function. • To activate this function touch . The symbol comes on.
  • Page 12: Helpful Hints And Tips

    Helpful hints and tips Activation of the sounds Deactivate the appliance. Touch for 3 seconds. The displays come on and go out. Touch for 3 seconds. comes on, because the sound is off. Touch comes on. The sound is on. HELPFUL HINTS AND TIPS Cookware •...
  • Page 13: Care And Cleaning

    Care and cleaning Heat Use to: Time Hints setting Cook larger quantities of food, stews 60-150 Up to 3 l liquid plus ingredients. and soups 9-12 Gentle fry: escalope, veal cordon bleu, as nec- Turn halfway through. cutlets, rissoles, sausages, liver, roux, essary eggs, pancakes, doughnuts 12-13...
  • Page 14: What To Do If

    What to do if… WHAT TO DO IF… Problem Possible cause and remedy You cannot activate the appli- • Activate the appliance again and set the heat setting in 10 ance or operate it. seconds. • You touched 2 or more sensor fields at the same time. Only touch one sensor field.
  • Page 15: Environment Concerns

    Environment concerns ENVIRONMENT CONCERNS The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
  • Page 16 Warranty Electrolux warrants that, when dispatched from an Electrolux warehouse, the Appli- ance is free from defects in materials and workmanship for the Warranty Period. During the Warranty Period Electrolux or its Authorised Service Centre will, at no extra charge if your appliance is readily accessible without special equipment, and subject to these terms and conditions, repair or replace any parts which it considers to be defec- tive.
  • Page 17 11. Provisions of the Trade Practices Act and State consumer legislation in Australia, and the Consumer Guarantees Act, the Sale of Goods Act and the Fair Trading Act in New Zealand, imply warranties or conditions, or impose obligations, upon Electrolux which cannot be excluded, restricted or modified.
  • Page 18 Canada Tel 905-829.3980 Fax 905-829.3985 email For Service & Spares: EURO-PARTS 1.800.678.8352 Important: Please record details of your purchase below and mail or fax to AEG -----------------------------------------------------------------------------------------cut along line ------------------------------------------------------------------------------------ Name: TEL No Address: City : State: Zip Code:...
  • Page 19 AEG appliances are imported and distributed in North America by Euro-Line Appliances Inc. For more information visit / 871 Cranberry Court 2912 West 4th Ave Oakville, ON L6L 6J7 Vancouver, BC V6K 1R2 Canada Canada Toll Free: 1.800.421.6332 Toll Free: 1.855.352-9378...
