- Page 3 A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs provided through satellite. This user's guide covers the installation of the DSR and the necessary steps to implement various features. This also explains special features available only in this DSR in detail, which will allow you to make full of these feature.
- Page 4 For Your Safety To avoid electric-shock hazards, do not Keep the receiver away from flower vases, open the cabinet, refer servicing to qualified tubs, sinks, etc., in order to avoid damaging personnel only. the equipment. Do not expose the receiver un-der the Do not block ventilation holes of the sunlight.
- Page 5 Function Turns power ON/OFF of the DSR When watching a channel, mute the sound Enter number of the required menu item or select a channel number to watch TV/RADIO Switches between TV and Radio mode Switches back to previous channel Display the favorite group list Show information of the current channel INFO...
- Page 6 Name and Function of Each Part on the Front Panel(optional) Name and Function of Each Part on the Rear Panel(optional) 1. LNB IN: CONNECT TO SATELLITE ANTENNA 2. AUDIO(R)/AUDIO(L):CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER 3. VEDIO:CONNECT VIDEO TO TV USING RCA JACK 4.
- Page 7 Main Menu Make sure that you have properly installed and connected the cables of the receiver well. If the receiver is the factory status or there is no program list, when power on, the Main Menu window will be displayed on the screen. During the normal TV/Radio mode, press MENU key on the RCU to enter into the Main Menu window.
- Page 8 Please input password which is 0000 when you want to do the operation us belows. 1)Press RED colour key to move the Delete button upward. Select the program and press red key to mark this program with the deletion mark. You can cancel this mark by pressing RED key again.
- Page 9 6) Press number key 6 to enter sort window. A-Z Key: The ascending order, omitting the $ character, the number is ahead, then the capital letter, at last the lowercase. Z-A Key: The opposite order of the above Name (A-Z). Free/Scramble: All FTA programs are listed ahead, while all scrambled programs are listed last.
- Page 10 2.3 Delete Satellite In delete satellite window,Select the program and press OK key to mark this program with the deletion mark.You can cannel this mark by pressing ok key again. Press EXIT key to pop up the dialogue "Are you sure to save?"Select OK button and press OK key to save,or select Cannel button and press OK key to exit without saving.
- Page 11 2.7 PID Search Satellite:Press keys to select in circle. TP:Press keys to select proper TP. TP Frequency,Symbol Rate,VideoPID, Audio PID,PCR PID:Use numeric keys to input the proper value. Polarity:Select between H and V. Press OK key at the Search channel. Edit Satellite:Operation same as 2.1.
- Page 12 3.5 OSD Setting M e n u C o l o r : P r e s s k e y s t o s e l e c t a m o n g style1,style2,style3,style4,style5.The default option is style1. T r a n s p a r e n c e : P r e s s k e y s t o s e l e c t...
- Page 13 4.3 Software Upgrade Please input password which is 0000 when you want to do the operation us belows. U p g r a d e M o d e: P r e s s k e y s t o s e l e c t a m o n g All,Code,Logo,Program List.The default option is All.
- Page 14 5.8 Audio 1. Press keys to enter into the Audio window. 2. Press keys to select between Left, Right and Stereo. 3. Changing the audio mode is only connected with the current channel, not all the channels. 4. Press MENU or EXIT key to close this window. 5.9 Recall Press key to switch the current channel to the previous channel.
- Page 15 Problem Possible causes What to do The display on the front Check that the main cable is plugged into Main cable is not connected. panel does not light up. the power socket. No sound or picture, but the receiver is in standby mode. Press the standby button.
