Warning:
Improper installation, adjustment,
alteration, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional
information consult a qualified installer,
service agency or the gas supplier.
What To Do If You Smell Gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
P/N XG0112
For Your Safety:
Do not store or use gasoline
or other flammable vapors
and liquids in the vicinity of
this or any other appliance.
MW38-DV Modular Fireplace
Installation
Operation &
Maintenance
MW38-DV
Modular
Gas Fireplace
Check local codes and
read all instructions
prior to installation.
Leave this manual with
the owner.
Page 1 of 19
Advertisement
Table of Contents
Related Manuals for Montigo Wildfire MW38-DV
Summary of Contents for Montigo Wildfire MW38-DV
- Page 1 MW38-DV Modular Fireplace Installation Operation & Maintenance MW38-DV Modular Gas Fireplace Warning: For Your Safety: Check local codes and Improper installation, adjustment, Do not store or use gasoline read all instructions alteration, service or maintenance can cause or other flammable vapors prior to installation.
-
Page 2: Table Of Contents
Table Of Contents Introduction About the Wildfire 38: Introduction ................2 The MW38-DV is a direct-vented gas fireplace equipped with a dual- inlet Wildfire® Burner. It is available in four models: Installation Top Vent (Product Code MW38-DT) Installing the Fireplace Shell ......... 3 Rear Vent (Product Code MW38-DR) Installing the Gasline ............. -
Page 3: Installation
These clearances apply to all dimensions except the framed opening, For Top Vent models (MW38DT), the minimum clearance is 13". where the clearance to combustibles is 0". The MW38-DV clearances (Minimum 1" clearance must still be maintained around the vent to combustible materials are: pipes.) -
Page 4: Installing The Gasline
Installation Installing The Gas Line Vent Installation The gas line must be installed before finishing the MW38-DV Fire- This section covers the installation of direct venting and terminations. place. Natural Gas requires a minimum inlet gas supply pressure of Installation Requirements 5.5"... - Page 5 MW38-DV Modular Fireplace Installation Installing Terminations with Built-In Frames termination may not be easily installed from the building's exterior. Frame the termination opening to 12" x 12". Fasten the MOSR frame to the interior side of the studs using a minimum of 4 screws.
-
Page 6: Direct Vent Installation
If the vertical dimension from the hearth is 84" and Installation Of Top Vent DV the horizontal run to the wall flange of the vent termination is 36", this would be an acceptable The following venting components are available for the MW38-DV installation. Top Vent: Example B: (Acceptable Installation) A - Termination MTO-3 (3"... -
Page 7: Terminations
MW38-DV Modular Fireplace Installation Top Vent Example 1: 150" max. For our shortest venting configuration use components A and F (see 30" max. Figure 9a). This configuration is suitable for installations where the Heat fireplace backs directly against 4" stud wall. For deeper walls, use an... - Page 8 MW38-DV Modular Fireplace Installation Top Vent Installation Of Vertical Vent DV Vertical Terminations must be installed: A maximum of two offsets with 90° bends may be made and shall not • minimum 2' (two feet) above the highest point where exceed total length of 25% of the vertical vent height, when measured vent passes through the roof.
- Page 9 MW38-DV Modular Fireplace Installation Rear Vent Rear Vent Venting Runs The MD38-DV Rear Vent has three possible installations which do 2. 45° Corner Installation. not require vertical lift: Attach an EEL-45 (45° elbow) directly onto the flue collar. Cut the EXT-18 to suit, and attach it to the EEL-45.
-
Page 10: Rear Vent Models
B. Multi-Elbow Installations Installation Of Rear Vent DV For more diffiicult installation situations, the MW38-DV Rear Vent may MW38-DV Rear Vent versions are supplied with an EXT-18 (female/ be installed with two - 90° elbows and up to 15' of horizontal run. If female) section. -
Page 11: Facing
Black touch. 115VAC White 24VAC Green Grnd Screw 40 VA Transformer Limit Wall Switch Switch Figure 20. Wiring for the MW38-DV-I with Honeywell gas control and pilot. P/N XG0112 Page 11 of 19... -
Page 12: Removing And Installing The Door
MW38-DV Modular Fireplace Installation Removing and Installing Wiring for the optional Fan Kit the Door All 38 Series Modular fireplaces feature an optional fan kit for circulating heat into the living space. Removing the door surround: Installations in Canada which employ the fans must be electrically The door surround is held in place by two metal clips at the top, and grounded in accordance with CSA C22.1 Canadian Electrical Code... -
Page 13: Installing The Log Set
Installing the Log Set insert. The MW38-DV is supplied with four (4) fibre logs. Logs "A" and "B" 5. Remove the insert by tipping the top of the insert outward and are permanently attached to the log rest, which is pre-installed by the lifting the tabs past the slots in the bottom of the shell. - Page 14 MW38-DV Modular Fireplace Operation - Model MW38-DV MW38-DV with Continuous Pilot For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 15: Lighting Instructions
MW38-DV Modular Fireplace Operation - Model MW38-DV-I MW38-DV-I with Honeywell Intermittent Pilot For Your Safety - READ BEFORE LIGHTING: WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 16: Operation
(Shown in "Pilot" postion.) Cleaning Figure 25. 'Hi-Lo' Adjustment on Model MW38-DV gas valve. When the fireplace is first activated, there may be some smoking and a visible film may be left on the glass. This is a normal condition, and is the result of burning of protective coatings on new metal. -
Page 17: Gas Control Valve
MW38-DV Modular Fireplace Maintenance Gas Control Valve Troubleshooting MW38-DV-I HONEYWELL SV 9500 /SV9600 Power Generator Troubleshooting Sequence Pilot Adjustment Screw NOTE: Before Troubleshooting, Familiarize Yourself With Wall Switch The Startup And Checkout Procedure. START INSET CHECK: · Turn Gas Supply off ·... -
Page 18: Warranty
The duration of any implied warranty with respect to this Montigo Gas Appliance is limited to the duration of the foregoing warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above may not apply to you. -
Page 19: Spare Parts
MW38-DV Modular Fireplace Appendix A - Spare Parts 1. Fan Kit () 2. Termination (MTKO/ETKO) 3. Termination Frame (MSR) 4. Termination Frame (MOSR) 5. Termination Frame - Brick (BSR) 6. Heat Guard (MTKOG) 7. Wildfire 4-piece Logset 8. 4-Piece Picture Frame Surround (PFS) 9. -
Page 20: Termination Locations
MW38-DV Modular Fireplace Appendix B - Termination Locations P/N XG0112 Page 20 of 19... - Page 21 MW38-DV Modular Fireplace XG0112 Rev. 04 - 04/99 Montigo Del Ray Corp. Canadian Heating Products Inc. Surrey, BC V3W 2V6 Ferndale, WA 98248 P/N XG0112 Page 21 of 19...
