reading a MaP

a B c
A2/E35 Utrecht
Marc Bloch Marc Bloch
30
Avenue Léon Avenue Léon
Avenue du Golf Avenue du Golf
LW 10245 66
J i H
Map key
A Warning of the next risk area with
the related distance (fixed or mobile
safety camera, school, etc .) .
B Name of the next major road or road
sign information, if applicable .
C Traffic sidebar: display of incidents
on the route, traffic info reception in-
dicator .
D Current time .
E Distance to and indication of next
change of direction .
F Exterior temperature (depending on
the vehicle) .
G Information about your journey, such
d e as remaining distance, journey time
and arrival time .
note: to select what will be shown,
select Change preferences" in the
6:47
main menu, then Status bar prefer-
ences" .
300
H Audio system information .
metres
I Current location .
4.5
14
km
J Sign giving the speed limit (the speed
km
0:05
h
given depends on the unit chosen) .
6:52
note: the sign turns red and flashes
26°C
RDS-AF
if you drive faster than the speed limit
g F
colour codes
The roads are displayed differently de-
pending on the type of carriageway .
You have the option to change the col-
ours: in the main menu (MENU button),
select "Change preferences" then
"Change map colors" .
K
A2/E35 Utrecht
Marc Bloch Marc Bloch
30
Avenue Léon Avenue Léon
Avenue du Golf Avenue du Golf
LW 10245 66
L
Map icons
The navigation system uses icons K to
display points of interest (POI) .
compass
To display or remove the compass L,
from the main menu (button "MENU"),
select "Change preferences", then
"Show compass" .
6:47
300
metres
4.5
14
km
km
0:05
h
6:52
26°C
RDS-AF
17
