Technical Specifications - HP Encryption SAN Specifications

QuickSpecs

Technical Specifications

System Architecture Fibre Channel ports
Scalability
Certified maximum
Ethernet Ports
Smart Cards
Interoperability
Encryption
Data rekeying
Crypto scalability
Crypto engine
Fibre Channel
performance
ISL Trunking
Aggregate bandwidth
Maximum frame size
Classes of service
Port types
Data traffic types
Media types
USB
Fabric services
FIPS certification
DA - 13219 Worldwide — Version 21 — December 9, 2013
32 ports, universal (E, F, and FL)
Full fabric architecture:
http://h18006.www1.hp.com/products/storageworks/san/documentation.html
Refer to SAN Design Guide for current configuration information:
http://h18006.www1.hp.com/products/storageworks/san/documentation.html
Two redundant 1000Base Ethernet ports for clustering and I/O synchronization
during rekeying
Master key recovery cards
Core Switch 2/64, SAN Switch 2/32, SAN Director 2/128; 4/256 SAN Director;
4/64 SAN Switch; 4/32 SAN Switch; 4/8 SAN Switch; 4/16 SAN Switch; 8/8 SAN
Switch, 8/24 SAN Switch, 8/8 40 SAN Switch; 8/80 SAN Switch, DC04 SAN
Director, DC SAN Backbone Director, Brocade 4Gb SAN Switch for HP p-Class
BladeSystem; Brocade 4Gb SAN Switch for HP c-Class BladeSystem; HP 400 MP-
Router; and HP MP-Router
AES256-XTS block cipher for disk encryption (IEEE 1619- compliant)
Online or offline conversion of data from cleartext to ciphertext; manual or
automated rekeying sessions
Up to 256 target devices; 1024 host ports per encryption
Maximum 48 Gbit/sec hardware processing for
1.063 Gbit/sec line speed, full duplex; 2.125 Gbit/sec line speed, full duplex;
4.25 Gbit/sec line speed, full duplex; 8.5 Gbit/sec line speed, full duplex. Auto-
sensing of 1 Gbit/sec, 2 Gbit/sec, 4 Gbit/sec, and 8 Gbit/sec port speeds;
optionally programmable to fixed port speed. Speed-matching between 1, 2, 4,
and 8 Gbit/sec ports.
Frame-based trunking with up to eight 8Gb ports per ISL trunk; up to 64 Gbit/sec
throughput per ISL trunk
512 Gbit/sec full duplex (32 ports x 8.5 Gbit/sec x 2)
2112-byte payload
Class 2 (unencrypted traffic), Class 3, (encrypted and unencrypted), and Class F
(inter-switch frames)
FL_Port, F_Port, E_Port, EX_Port, M_Port (Mirror Port).
Fabric switches supporting unicast, multicast (255 groups), and broadcast
Hot-pluggable, B-Series Branded Small Form Factor Pluggable (SFP), LC
connector; Short-Wave Laser (SWL), Long-Wave Laser (LWL); Extended Long-
Wave Laser (ELWL); distance depends on fiber-optic cable and port speed.
Supports SFP (4/2/1 Gbit/sec) and/or SFP+ (8/4/2 Gbit/sec) optical transceivers.
One USB port for system log file downloads or firmware upgrades
Simple Name Server (SNS), Registered State Change Notification (RSCN), NTP
v3, Reliable Commit Service (RCS), Dynamic Path Selection (DPS), Advanced
Zoning (default zoning, port/WWN zoning, broadcast zoning), N_Port ID
Virtualization (NPIV), FDMI, Management Server, FSPF, Enhanced Group
Management, IPFC, Frame Redirection, Port Fencing, BB credit recovery
Optional fabric services: Fabric Watch, Extended Fabrics, ISL Trunking, Advanced
Performance Monitoring, Adaptive Networking (per-data flow QoS, Ingress Rate
Limiting, Traffic Isolation, Fabric Dynamics Profiling, and Integrated Routing)
FIPS 140-2 Level 3-compliant package
HP Encryption SAN Switch
disk*
