QuickSpecs
Overview
Managing operational risk by protecting valuable digital assets has become increasingly critical in today's enterprise IT environments.
In addition to achieving compliance with regulatory mandates and meeting industry standards for data confidentiality, IT organizations
must also protect against potential litigation and liability following a reported breach.
The HP Encryption SAN Switch scales non-disruptively, providing 48 Gbit/sec of encryption processing power to meet the needs of the
most demanding environments with flexible, on-demand performance. It also is tightly integrated with HP Secure Key Manager and HP
Enterprise Secure Key Manager which provide centralized enterprise-class key management systems across distributed environments.
The HP Secure Key Manager and HP Enterprise Secure Key Manager enable simple yet secure key sharing between multiple sites for a
variety of uses. The capabilities of the HP Secure Key Manager and the HP Enterprise Secure Key Manager and their integration with the
Encryption SAN Switch enable secure and automated key sharing between multiple sites ensuring transparent access to encrypted
data.
The storage fabric enables centralized management to support nearly every aspect of the data center, from server environments and
workstations to edge computing and backup environments. As a result, it is an ideal place to standardize and consolidate a holistic
data-at-rest security strategy. Organizations can also implement this type of best-practice methodology in other parts of the data
center, helping to protect data throughout the enterprise.
The Encryption SAN Switch is based on industry standards for data-at-rest encryption to provide centralized, scalable encryption
services that seamlessly integrate into existing B-Series Fabric OS® (FOS) environments.
The B-Series fabric-based approach to data encryption scales to meet performance requirements and provides a centralized point of
management for storage security and key management. Deployment of the Encryption SAN switch is non-disruptive: Organizations can
encrypt data from any switch port without reconfiguring the fabric.
1. Status Led
2. Power led
3. RJ-45 GE ports (for clustering and re-keying)
4. Smart Card reader
What's New
New RoHS compliant HP SAN switches
NOTE: Restriction of Hazardous Substances Directive or RoHS is a directive adopted by the European Union that restricts the use of
certain hazardous materials in the manufacture of various types of electronic and electrical equipment. The RoHS compliant products
with new part numbers listed in this document are functionally equivalent to the corresponding products with old part numbers and are
fully interchangeable.
HP Encryption San Switch
DA - 13219 Worldwide — Version 21 — December 9, 2013
5. RJ-45 GE management port
6. RJ-45 serial console port
7. USB port
8. Fibre Channel ports (0-31)
HP Encryption SAN Switch
Page 1

Advertising

   Related Manuals for HP Encryption SAN

   Summary of Contents for HP Encryption SAN

  • Page 1

    The HP Secure Key Manager and HP Enterprise Secure Key Manager enable simple yet secure key sharing between multiple sites for a variety of uses. The capabilities of the HP Secure Key Manager and the HP Enterprise Secure Key Manager and their integration with the Encryption SAN Switch enable secure and automated key sharing between multiple sites ensuring transparent access to encrypted data.

  • Page 2: Features And Benefits, Key Features And Benefits

    Scalable performance with on-demand encryption processing power to meet regulatory mandates for protecting data NOTE: Encryption with the HP Encryption SAN Switch and the HP Encryption FC Blade is not fully supported with Thin Provisioned LUNs in storage arrays. HP recommends LUNs to be encrypted are fully provisioned. For LUNs that are already thin provisioned and then encryption enabled, be aware that enabling First Time Encryption (FTE) or Re-Key will make the LUN fully provisioned.

  • Page 3

    QuickSpecs HP Encryption SAN Switch Models HP Encryption SAN Switch HP Encryption SAN Switch AR944B Model DA - 13219 Worldwide — Version 21 — December 9, 2013 Page 3...

  • Page 4: Product Highlights

    Smart Cards Smart Cards are optional credit card-sized cards that contain a CPU and persistent memory. Smart cards can be used as security devices. With the Encryption SAN Switch, smart cards can be used to do the following: Control user access to the Management application security administrator roles.

  • Page 5

    QuickSpecs HP Encryption SAN Switch Product Highlights Software Components, Standard, Base Models Encryption Provides 48 Gbit/sec of data at rest encryption processing power to meet the needs of the most demanding environments with flexible, on-demand performance. Frame Filtering An ASIC based capability that enables new applications and features. The switch has the ability to "view"...

  • Page 6

    NOTE: SAO requires Brocade HBA installed in the server Software Components, Optional Encryption SAN Switch The Power Pack+ Software Bundle is an optional software bundle for the Encryption SAN Switch. It includes the following: Power Pack+ Software Bundle...

  • Page 7

    Integrated Routing provides architecture flexibility to route on a port-by-port basis, enabling increased scalability and fault isolation. SAN Network Advisor HP SAN Network Advisor Professional is a management application available at no-charge and comes with B-series SAN Switches and: Professional...

  • Page 8

    HP Encryption SAN Switch Product Highlights ports, while HP SAN Network Advisor Professional+ scales to 4 SAN Fabrics and 2560 switch ports. To accommodate growth, there is an upgrade available to SAN Network Advisor Enterprise from SAN Network Advisor Professional Plus.

  • Page 9

    HP Care Pack Services. Scalable, Flexible, Dependable. Like your storage. Your storage is evolving. Get scalable support that evolves with it. HP Care Pack Services is an easy-to-buy, easy-to-use portfolio of packaged services covering your lifecycle needs. You can rely on our highly skilled, HP certified professionals to offer a breadth of expertise across leading storage technologies, and work side by side with you for optimal results.

  • Page 10

    Service and Support, HP Care Pack, and Warranty Information Recommended Services HP Care Pack Services recommended for optimal satisfaction of all deployments of your product. 3-Year HP Support Plus 24 24x7x365 hardware and software services - plus cost-saving software updates and more HP Support Plus 24 helps you increase performance and availability with comprehensive, consistent hardware and software services.

  • Page 11

    HP eSupport is a portfolio of technology-based services that assist you with managing your business environment - from the desktop to the data center. Support Portal The HP support portal provides one-stop access to the information, tools and services you need to manage the daily operations of your IT environment. Features include:...

  • Page 12

    Service and Support, HP Care Pack, and Warranty Information Customer Technical Consider education as an integral part of your strategy to get the best return on investment for your HP storage solution. HP offers a variety of training courses on storage software, networking, archiving and Training disk storage systems.

  • Page 13: Configuration Information

    Step 2 - Options Model Description Part Number 8 Gb Transceivers HP 8Gb Shortwave B-series Fibre Channel 1 Pack SFP+ Transceiver AJ716B HP 8Gb Long Wave B-series 10km Fibre Channel 1 Pack SFP+ Transceiver AJ717A Distance OM2 Cable OM3 Cable PremierFlex Cable...

  • Page 14

    QuickSpecs HP Encryption SAN Switch Configuration Information HP LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable AJ839A Step 3 - Optional Software Software for Encryption HP B-series SAN Network Advisor Enterprise LTU TC352A SAN Switch HP B-series SAN Network Advisor Professional Plus LTU...

  • Page 15: Technical Specifications

    4/64 SAN Switch; 4/32 SAN Switch; 4/8 SAN Switch; 4/16 SAN Switch; 8/8 SAN Switch, 8/24 SAN Switch, 8/8 40 SAN Switch; 8/80 SAN Switch, DC04 SAN Director, DC SAN Backbone Director, Brocade 4Gb SAN Switch for HP p-Class BladeSystem; Brocade 4Gb SAN Switch for HP c-Class BladeSystem; HP 400 MP- Router;...

  • Page 16

    The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
