Operator's Handbook
Monarch 9417
Food Freshness System
0
28028
TC9417OH Rev. A
/13
®
©2013 Avery Dennison Corp. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Monarch 8417 and is the answer not in the manual?

Questions and answers

Related Manuals for Avery Dennison Monarch 8417

Summary of Contents for Avery Dennison Monarch 8417

  • Page 1 Operator’s Handbook Monarch 9417 ® Food Freshness System 28028 ©2013 Avery Dennison Corp. All rights reserved. TC9417OH Rev. A...
  • Page 2 Each product and program carries a respective written warranty, the only warranty on which the customer can rely. Avery Dennison reserves the right to make changes in the product, the programs, and their availability at any time and without notice. Although Avery Dennison has made every effort to provide complete and accurate information in this manual, Avery Dennison shall not be liable for any omissions or inaccuracies.

  • Page 3: Table Of Contents

    T A B L E O F C O N T E N T S GETTING STARTED ........................1-1 Using This Manual ........................1-1 Audience ..........................1-1 Printer Overview ........................1-2 Connecting the Power Cord ....................... 1-2 Loading Labels –...
  • Page 4 ii Operator’s Handbook...

  • Page 5: Getting Started

    G E T T I N G S T A R T E D Use the Monarch® FreshMarx® 9417 Food Freshness System for product freshness and to label inventory. The printer is available as a single printer (left printer only) or dual printer (left and right printer).

  • Page 6: Printer Overview

    P r i n t e r O v e r v i e w 1. Cover 6. Power Cord Connection 2. Display 7. Ethernet Port 3. Left Printer 8. USB (Type B) Port 4. Right Printer 9. USB (Type A) Port 5.

  • Page 7: Loading Labels - Left Printer

    L o a d i n g L a b e l s – L e f t P r i n t e r Turn on the printer. Press the power button on the side of the printer. Open the cover. Pull on the supply tab.
  • Page 8 Place the supply guide on the supply holder until it touches the supply. Lock the supply guide. Put the supply tab back. Guide the labels along the inside edge and into the slot (behind the white roller). The printer feeds the supply. Note: Tear a straight edge on the supply before feeding it into the printer.
  • Page 9 Slide the supply lever next to the supply. Close the supply lever. Close the cover. Getting Started 1-5...

  • Page 10: Loading Labels - Right Printer

    L o a d i n g L a b e l s – R i g h t P r i n t e r 1. Turn on the printer. Press the power button on the side of the printer. 2.
  • Page 11 5. Place a roll of labels (label side up) on the supply holder. 6. Place the outer supply guide on the supply holder and lock it in place. 7. Unlock the inner supply guide and move it until it touches the supply. Lock it into place. 8.
  • Page 12 9. Guide the labels along the outside edge and into the slot. The printer feeds the supply. Note: Tear a straight edge on the supply before feeding it into the printer. 10. Slide the supply lever next to the supply and close it. 11.

  • Page 13: Printing Labels

    P R I N T I N G L A B E L S This chapter describes how to  use the application  print freshness labels  print Use First labels. A b o u t t h e S y s t e m The main screen consists of a language toggle button, tools button, five product category buttons, each with six tabs of product buttons, and a “Use First”...

  • Page 14: Printing Freshness Labels

    P r i n t i n g F r e s h n e s s L a b e l s 1. Turn on the printer. 2. Press the product button of the label to print. Product Buttons 3.

  • Page 15: Printing Use First Labels

    P r i n t i n g U s e F i r s t L a b e l s Apply a “Use First” label to any product that needs to be used first. 1. Press the Use First category button on the right side of the screen. Use First Button 2.
  • Page 16 2-4 Operator’s Handbook...

  • Page 17: Care & Maintenance

    C A R E & M A I N T E N A N C E This chapter tells you how to  clear label jams  clean the platen roller and printhead  clean the printer. C l e a r i n g L a b e l J a m s To clear a jam: 1.

  • Page 18: Cleaning The Display

    3. Use the plastic knife to press the L-shaped bar. The platen roller is released. You may need to slightly open the front cover to eject the platen roller. Note: Art is cut-away to show detail. 4. Clean the platen roller and printhead using a cotton swab moistened with isopropyl alcohol. 5.

  • Page 19: Troubleshooting

    T R O U B L E S H O O T I N G This section lists some common printer problems and solutions. Problem Action The screen is off or the printer Press the Power Button to turn the printer off, press it is not responding.
  • Page 20 4-2 Operator’s Handbook...

  • Page 21: Specifications

    S P E C I F I C A T I O N S S y s t e m S p e c i f i c a t i o n s Height: 10.06” (255.55 mm) Width: 11.86" (301.41 mm) Depth: 8.36”...
  • Page 22 28028 Avery Dennison 170 Monarch Lane Miamisburg, OH 45342 1-800-543-6650 (In the U.S.A.) 1-800-387-4740 (In Canada) www.monarch.com...
